V- Max Drill A\
#


Cylindrical Adaptor Cylindrical Adaptor
2- M
\
i i
i i
o D2
D D1
!
D2
»
!
f
L1
L L

mm mm
Dimension Dimension
Designation M Drilling Range Designation M Drilling Range
D D1 D2 L LI D D1 D2 L
DXZ - 3016100 30 16 32 100 75 M8X0.75 YXZ - 3016100 30 16 16 100 M8X0.75
DXZ - 3013150 30 16 32 150 75 M8X0.75 YXZ - 3016200 30 16 16 200 M8X0.75 p45 -(p 55
(

DXZ - 3016200 30 16 32 200 75 M8X0.75 YXZ - 3016300 30 16 16 300 M8X0.75
q>45 - <p55
DXZ - 3016250 30 16 32 250 75 M8X0.75 YXZ -4525100 45 25 25 100 M10X1
DXZ - 3016300 30 16 32 300 75 M8X0.75 YXZ -4525200 45 25 25 200 M10X1 cp60-<p 80
DXZ - 3016400 30 16 32 400 75 M8X0.75 YXZ-4525300 45 25 25 300 M10X1
DXZ -4525100 45 25 40 100 75 M10X1 YXZ- 5030100 50 30 30 100 M12 X1
DXZ -4525150 45 25 40 150 75 M10X1 YXZ - 5030200 50 30 30 200 M12 X1 ( p85 -(p 95
DXZ -4525200 45 25 40 200 75 M10X1
q>60-cp80 YXZ - 5030300 50 30 30 300 M12 X1
DXZ -4525250 45 25 40 250 75 M10X1 YXZ - 5832100 58 32 32 100 M12 X1
DXZ -4525300 45 25 40 300 75 M10X1 YXZ - 5832200 58 32 32 200 M12 X1 Cp100-<p110
DXZ -4525400 45 25 40 400 75 M10X1 YXZ - 5832300 58 32 32 300 M12 X1
DXZ - 5030100 50 30 40 100 75 M12X1 YXZ -7040200 70 40 40 200 M12 X1
DXZ - 5030150 50 30 40 150 75 M12 X1 YXZ -7040300 70 40 40 300 M12 X1 cpI 15 -<pl 35
DXZ - 5030200 50 30 40 200 75 M12 X1 YXZ -7040400 70 40 40 400 M12 X1
<p85 -tp95
DXZ - 5030250 50 30 40 250 75 M12 X1 YXZ - 8050200 80 50 50 200 M12 X1
DXZ - 5030300 50 30 40 300 75 M12 X1 YXZ - 8050300 80 50 50 300 M12 X1 p140-(p195
(

DXZ - 5030400 50 30 40 400 75 M12 X1 YXZ - 8050400 80 50 50 400 M12 X1
DXZ - 5832100 58 32 40 100 75 M12 X1
DXZ - 5832150 58 32 40 150 75 M12X1
DXZ - 5832200 58 32 40 200 75 M12 X1
(pi 00- (pi 10
DXZ - 5832250 58 32 40 250 75 M12 X1
DXZ - 5832300 58 32 40 300 75 M12 X1 Cutting Condition Formula
DXZ - 5832400 58 32 40 400 75 M12 X1
DXZ -7040100 70 40 50 100 80 M12 X1
DXZ -7040150 70 40 50 150 80 M12X1
RPM = ( Vc x 1000) / (n x Dia.)
DXZ -7040200 70 40 50 200 80 M12X1 Tc = H / ( Vf x 60) Vf = fn x RPM (mm/ min)
(pi 15-(p135
where:
DXZ -7040250 70 40 50 250 80 M12X1 where: where:
RPM = Revolution per minute ( rev/min)
DXZ -7040300 70 40 50 300 80 M12 X1 Tc = Drilling Time ( secs.) Vf = Feed per minute (mm/min)
Vc = Cutting speed (m/min)
DXZ -7040400 70 40 50 400 80 M12X1 H = Drilling depth (mm) fn = Feed per revolution (mm/rev )
7T = 3.1416
DXZ - 8050100 80 50 50 100 80 M12 X1 Vf = Feed per minute (mm/min) RPM = Revolution per minute ( rev/min)
Dia. = Diameter of drill (mm)
DXZ - 8050150 80 50 50 150 80 M12X1
DXZ - 8050200 80 50 50 200 80 M12 X1
(p140- (p195
DXZ - 8050250 80 50 50 250 80 M12X1
DXZ - 8050300 80 50 50 300 80 M12X1
DXZ 8050400
- 80 50 50 400 80 M12X1
