Каталог TooTool монолитные фрезы
| 4VFE 20020200V45100 | 20.0 | 20 | 45 | 100 | 2.0 | |
| 04004050V10075 | 4.0 | 4 | 10 | 75 | 0.5 | |
| 04004100V10075 | 4.0 | 4 | 10 | 75 | 1.0 | |
| 06006050V15075 | 6.0 | 6 | 15 | 75 | 0.5 | |
| 06006100V15075 | 6.0 | 6 | 15 | 75 | 1.0 | |
| 08008050V20075 | 8.0 | 8 | 20 | 75 | 0.5 | |
| 08008100V20075 | 8.0 | 8 | 20 | 75 | 1.0 | |
| 08008200V20075 | 8.0 | 8 | 20 | 75 | 2.0 | |
| 04004050V12100 | 4.0 | 4 | 12 | 100 | 0.5 | |
| 04004100V12100 | 4.0 | 4 | 12 | 100 | 1.0 | |
| 06006050V18100 | 6.0 | 6 | 18 | 100 | 0.5 | |
| 06006100V18100 | 6.0 | 6 | 18 | 100 | 1.0 | |
| 08008050V24100 | 8.0 | 8 | 24 | 100 | 0.5 | |
| 08008100V24100 | 8.0 | 8 | 24 | 100 | 1.0 | |
| 08008200V24100 | 8.0 | 8 | 24 | 100 | 2.0 | |
| 10010050V30100 | 10.0 | 10 | 30 | 100 | 0.5 | |
| 10010100V30100 | 10.0 | 10 | 30 | 100 | 1.0 | |
| 10010200V30100 | 10.0 | 10 | 30 | 100 | 2.0 | |
| 12012050V36100 | 12.0 | 12 | 36 | 100 | 0.5 | |
| 12012100V36100 | 12.0 | 12 | 36 | 100 | 1.0 | |
| 12012200V36100 | 12.0 | 12 | 36 | 100 | 2.0 | |
| 06006050V18150 | 6.0 | 6 | 18 | 5.8 | 150 | 0.5 |
| 06006100V18150 | 6.0 | 6 | 18 | 5.8 | 150 | 1.0 |
| 08008050V24150 | 8.0 | 8 | 24 | 7.8 | 150 | 0.5 |
| 08008100V24150 | 8.0 | 8 | 24 | 7.8 | 150 | 1.0 |
| 08008200V24150 | 8.0 | 8 | 24 | 7.8 | 150 | 2.0 |
| 10010050V30150 | 10.0 | 10 | 30 | 9.8 | 150 | 0.5 |
| 10010100V30150 | 10.0 | 10 | 30 | 9.8 | 150 | 1.0 |
| 10010200V30150 | 10.0 | 10 | 30 | 9.8 | 150 | 2.0 |
| 12012050V36150 | 12.0 | 12 | 36 | 11.8 | 150 | 0.5 |
| 12012100V36150 | 12.0 | 12 | 36 | 11.8 | 150 | 1.0 |
| 12012200V36150 | 12.0 | 12 | 36 | 11.8 | 150 | 2.0 |
| 14014050V42150 | 14.0 | 14 | 42 | 13.8 | 150 | 0.5 |
| 14014100V42150 | 14.0 | 14 | 42 | 13.8 | 150 | 1.0 |
| 14014200V42150 | 14.0 | 14 | 42 | 13.8 | 150 | 2.0 |
| 16016050V48150 | 16.0 | 16 | 48 | 15.8 | 150 | 0.5 |
| 16016100V48150 | 16.0 | 16 | 48 | 15.8 | 150 | 1.0 |
| 16016200V48150 | 16.0 | 16 | 48 | 15.8 | 150 | 2.0 |
| 18018050V54150 | 18.0 | 18 | 54 | 17.8 | 150 | 0.5 |
| 18018100V54150 | 18.0 | 18 | 54 | 17.8 | 150 | 1.0 |
| 18018200V54150 | 18.0 | 18 | 54 | 17.8 | 150 | 2.0 |
| 20020050V60150 | 20.0 | 20 | 60 | 19.8 | 150 | 0.5 |
| 20020100V60150 | 20.0 | 20 | 60 | 19.8 | 150 | 1.0 |
| 20020200V60150 | 20.0 | 20 | 60 | 19.8 | 150 | 2.0 |
| .15° | ||||||||
| 0D | Tolerance | Li | L | T | 35 | |||
| 02.5-09 | 0.00-0.02 | s | ||||||
| 010-016 | 0.00-0.03 | L1 | L | Car | (mm) bide | |||
| OrderCode | cfD | LI | Avoidance diameter | L | R | -H | RC62 | |
| TSM600 | PDL025 | |||||||
| 4VFE 03004050V08050 | 3.0 | 4 | 8 | 50 | 0.5 | |||
| 04004050V10050 | 4.0 | 4 | 10 | 50 | 0.5 | |||
| 04004100V10050 | 4.0 | 4 | 10 | 50 | 1.0 | |||
| 05005050V13050 | 5.0 | 5 | 13 | 50 | 0.5 | |||
| 05005100V13050 | 5.0 | 5 | 13 | 50 | 1.0 | |||
| 05006050V13050 | 5.0 | 6 | 13 | 50 | 0.5 | |||
| 05006100V13050 | 5.0 | 6 | 13 | 50 | 1.0 | |||
| 06006050V15050 | 6.0 | 6 | 15 | 50 | 0.5 | |||
| 06006100V15050 | 6.0 | 6 | 15 | 50 | 1.0 | |||
| 08008050V20060 | 8.0 | 8 | 20 | 60 | 0.5 | |||
| 08008100V20060 | 8.0 | 8 | 20 | 60 | 1.0 | |||
| 08008200V20060 | 8.0 | 8 | 20 | 60 | 2.0 | |||
| 10010050V25075 | 10.0 | 10 | 25 | 75 | 0.5 | |||
| 10010100V25075 | 10.0 | 10 | 25 | 75 | 1.0 | |||
| 10010200V25075 | 10.0 | 10 | 25 | 75 | 2.0 | |||
| 12012050V30075 | 12.0 | 12 | 30 | 75 | 0.5 | |||
| 12012100V30075 | 12.0 | 12 | 30 | 75 | 1.0 | |||
| 12012200V30075 | 12.0 | 12 | 30 | 75 | 2.0 | |||
| 14014050V35100 | 14.0 | 14 | 35 | 100 | 0.5 | |||
| 14014100V35100 | 14.0 | 14 | 35 | 100 | 1.0 | |||
| 14014200V35100 | 14.0 | 14 | 35 | 100 | 2.0 | |||
| 16016050V40100 | 16.0 | 16 | 40 | 100 | 0.5 | |||
| 16016100V40100 | 16.0 | 16 | 40 | 100 | 1.0 | |||
| 16016200V40100 | 16.0 | 16 | 40 | 100 | 2.0 | |||
| 18018050V40100 | 18.0 | 18 | 40 | 100 | 0.5 | |||
| 18018100V40100 | 18.0 | 18 | 40 | 100 | 1.0 | |||
| 18018200V40100 | 18.0 | 18 | 40 | 100 | 2.0 | |||
| 20020050V45100 | 20.0 | 20 | 45 | 100 | 0.5 | |||
| 20020100V45100 | 20.0 | 20 | 45 | 100 | 1.0 |
