| 2DBE | 02004100N30080 | 2.0 | 4 | 5.0 | 30 | 80 | 1.00 | 2 |
| 03004150V08060 | 3.0 | 4 | 8.0 | 60 | 1.50 | 2 | ||
| 03004150N20080 | 3.0 | 4 | 7.5 | 20 | 80 | 1.50 | 2 | |
| 03004150N25080 | 3.0 | 4 | 7.5 | 25 | 80 | 1.50 | 2 | |
| 03004150N30100 | 3.0 | 4 | 7.5 | 30 | 100 | 1.50 | 2 | |
| 04004200V10050 | 4.0 | 4 | 10.0 | 50 | 2.00 | 2 | ||
| 04004200N20080 | 4.0 | 4 | 10.0 | 20 | 80 | 2.00 | 2 | |
| 04004200N30080 | 4.0 | 4 | 10.0 | 30 | 80 | 2.00 | 2 | |
| 04004200N30100 | 4.0 | 4 | 10.0 | 30 | 100 | 2.00 | 2 | |
| 06006300N30080 | 6.0 | 6 | 15.0 | 30 | 80 | 3.00 | 2 | |
| 4DBE | 06006300N40110 | 6.0 | 6 | 15.0 | 40 | 110 | 3.00 | 4 |
| 06006300N50150 | 6.0 | 6 | 15.0 | 50 | 150 | 3.00 | 4 | |
| 08008400N40110 | 8.0 | 8 | 20.0 | 40 | 110 | 4.00 | 4 | |
| 08008400N50150 | 8.0 | 8 | 20.0 | 50 | 150 | 4.00 | 4 | |
| 10010500V40110 | 10.0 | 10 | 30.0 | 40 | 110 | 5.00 | 4 | |
| 10010500N50150 | 10.0 | 10 | 30.0 | 50 | 150 | 5.00 | 4 | |
| 12012600N50110 | 12.0 | 12 | 30.0 | 50 | 110 | 6.00 | 4 | |
| 12012600N60150 | 12.0 | 12 | 30.0 | 60 | 150 | 6.00 | 4 |
| II 12 | L | T3 O ? | |||||
| O O | T3O | ||||||
| 0D Tolerance | R | II | |||||
| -05.9 0.00-0.02 | 12 | ||||||
| 06.0- 0.00-0.03 | L | ||||||
| (mm) | |||||||
| OrderCode | 9D | cpd | II | 12 | L | R | No.of flutes |
| 2DBE 00504025N05050 | 0.5 | 4 | 1.2 | 5 | 50 | 0.25 | 2 |
| 00504025N10050 | 0.5 | 4 | 1.2 | 10 | 50 | 0.25 | 2 |
| 00604030N06050 | 0.6 | 4 | 1.5 | 6 | 50 | 0.30 | 2 |
| 00604030N08050 | 0.6 | 4 | 1.5 | 8 | 50 | 0.30 | 2 |
| 00604030N10050 | 0.6 | 4 | 1.5 | 10 | 50 | 0.30 | 2 |
| 00604030N15050 | 0.6 | 4 | 1.5 | 15 | 50 | 0.30 | 2 |
| 01004050V03060 | 1.0 | 4 | 3.0 | 60 | 0.50 | 2 | |
| 01004050N06060 | 1.0 | 4 | 2.5 | 6 | 60 | 0.50 | 2 |
| 01004050N08060 | 1.0 | 4 | 2.5 | 8 | 60 | 0.50 | 2 |
| 01004050N10060 | 1.0 | 4 | 2.5 | 10 | 60 | 0.50 | 2 |
| 01004050N15060 | 1.0 | 4 | 2.5 | 15 | 60 | 0.50 | 2 |
| 01004050N20060 | 1.0 | 4 | 2.5 | 20 | 60 | 0.50 | 2 |
| 01004050N10080 | 1.0 | 4 | 2.5 | 10 | 80 | 0.50 | 2 |
| 01004050N15080 | 1.0 | 4 | 2.5 | 15 | 80 | 0.50 | 2 |
| 01004050N20080 | 1.0 | 4 | 2.5 | 20 | 80 | 0.50 | 2 |
| 01504075N08060 | 1.5 | 4 | 4.0 | 8 | 60 | 0.75 | 2 |
| 01504075N12060 | 1.5 | 4 | 4.0 | 12 | 60 | 0.75 | 2 |
| 01504075N15060 | 1.5 | 4 | 4.0 | 15 | 60 | 0.75 | 2 |
| 01504075N20060 | 1.5 | 4 | 4.0 | 20 | 60 | 0.75 | 2 |
| 01504075N25080 | 1.5 | 4 | 4.0 | 25 | 80 | 0.75 | 2 |
| 01504075N30080 | 1.5 | 4 | 4.0 | 30 | 80 | 0.75 | 2 |
| 02004100V05060 | 2.0 | 4 | 5.0 | 60 | 1.00 | 2 | |
| 02004100N08060 | 2.0 | 4 | 5.0 | 8 | 60 | 1.00 | 2 |
| 02004100N10060 | 2.0 | 4 | 5.0 | 10 | 60 | 1.00 | 2 |
| 02004100N15060 | 2.0 | 4 | 5.0 | 15 | 60 | 1.00 | 2 |
| 02004100N20060 | 2.0 | 4 | 5.0 | 20 | 60 | 1.00 | 2 |
| 02004100N16080 | 2.0 | 4 | 5.0 | 16 | 80 | 1.00 | 2 |
| 02004100N20080 | 2.0 | 4 | 5.0 | 20 | 80 | 1.00 | 2 |
| 02004100N25080 | 2.0 | 4 | 5.0 | 25 | 80 | 1.00 | 2 |
