| 4DFE | 04004000N25080 | 4.0 | 4 | 10.0 | 25 | 80 | 4 |
| 06006000N30080 | 6.0 | 6 | 18.0 | 30 | 80 | 4 | |
| 06006000N40110 | 6.0 | 6 | 18.0 | 40 | 110 | 4 | |
| 06006000N50150 | 6.0 | 6 | 18.0 | 50 | 150 | 4 | |
| 08008000N40110 | 8.0 | 8 | 20.0 | 40 | 110 | 4 | |
| 08008000N50150 | 8.0 | 8 | 20.0 | 50 | 150 | 4 | |
| 10010000V40110 | 10.0 | 10 | 30.0 | 40 | 110 | 4 | |
| 10010000N50150 | 10.0 | 10 | 30.0 | 50 | 150 | 4 | |
| 12012000N50110 | 12.0 | 12 | 30.0 | 50 | 110 | 4 | |
| 12012000N60150 | 12.0 | 12 | 30.0 | 60 | 150 | 4 |
| T3 O | ||||
| X1& | a Q, | |||
| 0D Tolerance | ||||
| -05.9 0.00-0.02 | 12 | |||
| 06.0- 0.00-0.03 | L | |||
| (mm) | ||||
| OrderCode | 9D | 9d | II 12 L | No.of flutes |
| 2DFE 00504000N05050 | 0.5 | 4 | 1.0 5 50 | 2 |
| 00604000N06050 | 0.6 | 4 | 1.2 6 50 | 2 |
| 00604000N08050 | 0.6 | 4 | 1.2 8 50 | 2 |
| 00804000N08050 | 0.8 | 4 | 2.0 8 50 | 2 |
| 01004000V03060 | 1.0 | 4 | 3.0 60 | 2 |
| 01004000N06060 | 1.0 | 4 | 3.0 6 60 | 2 |
| 01004000N10060 | 1.0 | 4 | 3.0 10 60 | 2 |
| 01004000N15060 | 1.0 | 4 | 3.0 15 60 | 2 |
| 01004000N20060 | 1.0 | 4 | 3.0 20 60 | 2 |
| 4DFE 01504000V04060 | 1.5 | 4 | 4.0 60 | 4 |
| 01504000N10060 | 1.5 | 4 | 4.0 10 60 | 4 |
| 01504000N15060 | 1.5 | 4 | 4.0 15 60 | 4 |
| 01504000N20080 | 1.5 | 4 | 4.0 20 80 | 4 |
| 01504000N25080 | 1.5 | 4 | 4.0 25 80 | 4 |
| 02004000V06060 | 2.0 | 4 | 6.0 60 | 4 |
| 02004000N10060 | 2.0 | 4 | 6.0 10 60 | 4 |
| 02004000N12060 | 2.0 | 4 | 6.0 12 60 | 4 |
| 02004000N15060 | 2.0 | 4 | 6.0 15 60 | 4 |
| 02004000N20080 | 2.0 | 4 | 6.0 20 80 | 4 |
| 02004000N25080 | 2.0 | 4 | 6.0 25 80 | 4 |
| 02004000N30080 | 2.0 | 4 | 6.0 30 80 | 4 |
| 03004000V09050 | 3.0 | 4 | 9.0 50 | 4 |
| 03004000N20080 | 3.0 | 4 | 9.0 20 80 | 4 |
| 03004000N25080 | 3.0 | 4 | 9.0 25 80 | 4 |
| 03004000N30080 | 3.0 | 4 | 9.0 30 80 | 4 |
| 04004000V12050 | 4.0 | 4 | 12.0 50 | 4 |
| 04004000N20060 | 4.0 | 4 | 10.0 20 60 | 4 |
| 04004000N25060 | 4.0 | 4 | 10.0 25 60 | 4 |
| 04004000N20080 | 4.0 | 4 | 10.0 20 80 | 4 |
