DC LU
Глубина сверления: 3xD LPR LS
OAL
DCONMSh6 CNT DF
| Обозначение | DC | DCONMS | Ра DF | змеры( LU | мм) LPR | LS | CNT | Пластина |
| TOP 3255-25T2-08 | 25.5 | 25 | 32 | 78 | 99 | 56 | M16X1.5 | SOMT 08...DP/DL/DK/DA |
| 3255-32T2-08 | 25.5 | 32 | 40 | 78 | 99 | 60 | M22X2.0 | D146-147 |
| 3260-25T2-08 | 26.0 | 25 | 32 | 78 | 99 | 56 | M16X1.5 | |
| 3260-32T2-08 | 26.0 | 32 | 32 | 78 | 99 | 60 | M22X2.0 | |
| 3265-25T2-09 | 26.5 | 25 | 40 | 81 | 104 | 56 | M16X1.5 | SOMT 09...DP/DL/DK/DA |
| 3265-32T2-09 | 26.5 | 32 | 40 | 81 | 104 | 60 | M22X2.0 | D146-147 |
| 3270-25T2-09 | 27.0 | 25 | 40 | 81 | 104 | 56 | M16X1.5 | |
| 3270-32T2-09 | 27.0 | 32 | 40 | 81 | 104 | 60 | M22X2.0 | |
| 3275-25T2-09 | 27.5 | 25 | 40 | 84 | 107 | 56 | M16X1.5 | |
| 3275-32T2-09 | 27.5 | 32 | 40 | 84 | 107 | 60 | M22X2.0 | |
| 3280-25T2-09 | 28.0 | 25 | 40 | 84 | 107 | 56 | M16X1.5 | |
| 3280-32T2-09 | 28.0 | 32 | 40 | 84 | 107 | 60 | M22X2.0 | |
| 3285-25T2-09 | 28.5 | 25 | 40 | 87 | 110 | 56 | M16X1.5 | |
| 3285-32T2-09 | 28.5 | 32 | 40 | 87 | 110 | 60 | M22X2.0 | |
| 3290-25T2-09 | 29.0 | 25 | 40 | 87 | 110 | 56 | M16X1.5 | |
| 3290-32T2-09 | 29.0 | 32 | 40 | 87 | 110 | 60 | M22X2.0 | |
| 3295-32T2-09 | 29.5 | 32 | 40 | 90 | 113 | 60 | M22X2.0 | |
| 3300-32T2-09 | 30.0 | 32 | 40 | 90 | 113 | 60 | M22X2.0 | |
| 3305-32T2-09 | 30.5 | 32 | 40 | 93 | 116 | 60 | M22X2.0 | |
| 3310-32T2-09 | 31.0 | 32 | 40 | 93 | 116 | 60 | M22X2.0 | |
| 3320-32T2-11 | 32.0 | 32 | 40 | 96 | 119 | 60 | M22X2.0 | SOMT 11...DP/DL/DK/DA |
| 3320-40T2-11 | 32.0 | 40 | 50 | 96 | 119 | 70 | M30X2.0 | D146-147 |
| 3330-32T2-11 | 33.0 | 32 | 40 | 99 | 122 | 60 | M22X2.0 | |
| 3330-40T2-11 | 33.0 | 40 | 50 | 99 | 122 | 70 | M30X2.0 | |
| 3340-32T2-11 | 34.0 | 32 | 40 | 102 | 125 | 60 | M22X2.0 | |
| 3340-40T2-11 | 34.0 | 40 | 50 | 102 | 125 | 70 | M30X2.0 | |
| 3350-32T2-11 | 35.0 | 32 | 40 | 105 | 128 | 60 | M22X2.0 | |
| 3350-40T2-11 | 35.0 | 40 | 50 | 105 | 128 | 70 | M30X2.0 | |
| 3360-32T2-11 | 36.0 | 32 | 40 | 108 | 131 | 60 | M22X2.0 | |
| 3360-40T2-11 | 36.0 | 40 | 50 | 108 | 131 | 70 | M30X2.0 | |
| 3370-32T2-13 | 37.0 | 32 | 50 | 111 | 139 | 60 | M22X2.0 | SOMT 13...DP/DL/DK/DA |
| 3370-40T2-13 | 37.0 | 40 | 50 | 111 | 139 | 70 | M30X2.0 | D146-147 |
| 3380-32T2-13 | 38.0 | 32 | 50 | 114 | 142 | 60 | M22X2.0 | |
| 3380-40T2-13 | 38.0 | 40 | 50 | 114 | 142 | 70 | M30X2.0 | |
| 3390-32T2-13 | 39.0 | 32 | 50 | 117 | 145 | 60 | M22X2.0 |
