EndmillsSquareRadiusBallnoseMulti-PurposeGeneral-purposeHighEfficiencyHardene dSteelRoughingNon-ferrousMetalCFRPCoatedUncoated -0.040 DC -0.060 Stock DMM h6 -0.040 DC -0.060 ap DMM h6 AURORA Coat Square Endmills ASM 2000DL Type Aluminum CopperAlloyAlloy Aurora Corner Flutes Coat Helix Angle Side Milling Grooving Groove Finishing Face Milling Spot Facing Helical Milling Ramping Fig 1 Fig 2 APMX APMX LU θ LF LF DC θ I < ø3 10°≥ ø315° Body Dimensions (mm) Cat. No. Dia.DC Cutting Edge Length Neck Length Overall LengthAPMXLULF Shank Dia.DMM Fig ASM 2020DL ● 2.0 6.0 6.8 40 4 1 ASM 2030DL ● 3.0 10.0 12.9 45 6 1 ASM 2040DL ● 4.0 12.0 14.7 45 6 1 ASM 2050DL ● 5.0 15.0 18.6 50 6 1 ASM 2060DL ● 6.0 15.0 ― 50 6 2 ASM 2080DL ● 8.0 18.0 ― 60 8 2 ASM 2100DL ● 10.0 22.0 ― 71 10 2 ASM 2120DL ● 12.0 25.0 ― 75 12 2 ASM 2160DL ● 16.0 32.0 ― 90 16 2 Grade: DL1000 Recommended Cutting Conditions 1. If the machine cannot achieve the recommended spindle speed, please use the maximum spindle speed available. 2. If cutting noise and vibration occur, please reduce the cutting conditions accordingly. DC Groove Milling Work Material Aluminum Alloy Cutting Conditions Wet Dry DC (mm) Spindle Speed Feed Rate Spindle Speed Feed Rate(min-1)(mm/min)(min-1)(mm/min) 2.0 28,000 280 28,000 200 3.0 22,000 400 22,000 280 4.0 18,000 520 18,000 360 5.0 14,000 520 14,000 360 6.0 12,000 540 12,000 370 8.0 9,000 540 9,000 370 10.0 7,200 560 7,200 390 12.0 6,000 560 6,000 390 16.0 4,500 560 4,500 390 Standard ap 1.0DC 0.5DC Depth of Cut ae 1.0DC 1.0DC I94
