EndmillsSquareRadiusBallnoseMulti-PurposeGeneral-purposeHighEfficiencyHardene dSteelRoughingNon-ferrousMetalCFRPCoatedUncoated Stock -0.030 DC -0.060 DMM h6ap ZX Coated Extra Long Hard Endmills EHHM 6000ZX Type General CarbonSteelSteelAlloySteelPre-hardenedSteelTemperedSteel/Die SteelHardenedSteel45 to 55HRCHardenedSteel55 to 60HRC Corner Flutes Coat Helix Angle Side Milling Face Milling Fig 1 APMX LF I Body (6 Flutes) Dimensions (mm) Cat. No. Dia.DC Cutting Edge Length Overall LengthAPMXLF Shank Dia. DMM Fig EHHM 6060ZX ● 6.0 30.0 70 6 1 EHHM 6080ZX ● 8.0 40.0 90 8 1 EHHM 6100ZX ● 10.0 50.0 100 10 1 EHHM 6120ZX ● 12.0 50.0 120 12 1 Grade: ACZ10M Recommended Cutting Conditions 1. If the machine cannot achieve the standard spindle speed, please use the maximum spindle speed available. 2. If cutting noise and vibration occur, please reduce the cutting conditions accordingly. ae Side Milling Work Material Carbon Steel / Alloy Steel Carbon Steel / Alloy Steel Hardened Steel Cast Iron Cutting (Below 25HRC)Conditions (Below 45HRC) (Below 65HRC) Special Cast Iron DC (mm) Spindle Speed Feed Rate Spindle Speed Feed Rate Spindle Speed Feed Rate Spindle Speed Feed Rate(min-1)(mm/min)(min-1)(mm/min)(min-1)(mm/min)(min-1)(mm/min) 6.0 2,900 810 2,300 590 900 160 2,900 810 8.0 2,400 860 2,000 620 800 170 2,400 860 10.0 2,100 920 1,800 650 700 170 2,100 920 12.0 1,750 880 1,500 580 600 170 1,750 880 Standard ap 2.0DC 2.0DC 2.0DC 2.0DC Depth of Cut ae 0.05DC 0.02DC 0.01DC 0.05DC I88
