Milling CuttersFace MillingShoulde rMillingHigh FeedMulti-PurposeRadiusR / 3DProfilingGroove /T-SlotChamferingNon-ferrousMetalHigh-speedCast Iron Metric Stock DC D1 D2 KWW DCB DCSFMS SEC-Sumi Dual Mill TSXR 13000R(S) Type Steel Stainless Steel Cast Iron Exotic Alloy Radial –23 to –15° Rake Angle to Axial –6 to –3° Fig 1 CBDP KDP APMX H LF Body  Dimensions (mm) Cat. No. Dia. Max. Depth of Cut BossDCAPMXDCSFMSHeightLFBore Dia. Keyway Width Keyway Depth Mounting Depth BoltDCBKWWKDPCBDPD1Bolt D2 Total No. of Teeth Steps Effective No. of Teeth Weight (kg) Fig TSXR 13040RS4116Z02 ● 40 41 37 60 16.0 8.4 5.6 18.0 14 9 8 4 2 0.31 1 TSXR 13050RS6022Z03 ● 50 60 47 80 22.0 10.4 6.3 20.0 18 11 18 6 3 0.66 1 TSXR 13063RS5027Z03 ● 63 50 60 75 27.0 12.4 7.0 22.0 20 14 15 5 3 1.12 1 TSXR 13063RS6027Z04 ● 63 60 60 80 27.0 12.4 7.0 22.0 20 14 24 6 4 1.15 1 TSXR 13080RS6032Z04 ● 80 60 77 80 32.0 14.4 8.0 26.0 25 18 24 6 4 2.06 1 TSXR 13080RS6032Z05 ● 80 60 77 80 32.0 14.4 8.0 26.0 25 18 30 6 5 2.04 1 TSXR 13100RS6040Z05 ● 100 60 88 85 40.0 16.4 9.0 29.0 32 21 30 6 5 3.45 1 TSXR 13100RS6040Z06 ● 100 60 88 85 40.0 16.4 9.0 29.0 32 21 36 6 6 3.44 1 TSXR 13125RS6040Z07 ● 125 60 100 85 40.0 16.4 9.0 29.0 32 21 42 6 7 5.63 1 Inserts are sold separately. Identification Code TSXR 13 050 R S 60 22 Z03 Cutter Series Insert Size Cutter Dia. Feed Direction Metric Max. Depth Mounting Hole Effective No. Bore of Cut Diameter of Teeth Parts Screw Wrench Detachable WrenchHandle GripBit Bolt Anti-seizure Cream Applicable Cutter Nm TSXR 13040RS4116Z02 BX0850 TSXR 13050RS6022Z03TSXR 13063RS5027Z03 Q HPS1015 TRB15IP BX1060 BX1260 TSXR 13063RS6027Z04 BX1265 TSXR 13080RS6032Z04 BFTX03510IP 3.0TSXR 13080RS6032Z05 BX1660 SUMI-P TSXR 13100RS6040Z05 TRDR15IP Q Q TSXR 13100RS6040Z06 BX2065 TSXR 13125RS6040Z07 H126 N m Recommended Tightening Torque (N·m) ● mark: Standard stocked item (new product/expanded item)
