Milling CuttersFace MillingShoulde rMillingHigh FeedMulti-PurposeRadiusR / 3DProfilingGroove /T-SlotChamferingNon-ferrousMetalHigh-speedCast Iron MetricInch CBDP KDP Stock LF CBDP KDP LF CBDP KDP LF CBDP KDP LF CBDP KDP LF CBDP KDP LF SEC-Sumi Dual Mill TSXM 13000R(S) Type Steel Stainless Steel Cast Iron Exotic Alloy Radial -23° to 15° Rake Angle Axial -6° Fig 1 Fig 2 Fig 3 Fig 4 Fig 5 Fig 6 DCSFMS DCSFMS ø177.8 DCSFMS DCSFMS DCSFMS DCSFMS ø101.6 (*1) ø101.6 DCB DCB DCB DCB DCB DCB 4-ø18 KWW KWW KWW KWW KWW 4-ø18 (*2) KWW 4-ø22 D2 D3 D1 D1 D1 D1 D1 D2 DC DC DC DC H DC D1DC For TSXM 13160RS*1: ø66.7 *2: 4-ø14 Body (Fine Pitch)  Dimensions (mm) Cat. No. Dia. Boss Height Bore Dia. Keyway Width Keyway Depth Mounting Depth BoltDCDCSFMSLFDCBKWWKDPCBDPD1 BoltD2 BoltD3 Number Weightof Teeth(kg)Fig TSXM 13040RS ● 40 33 40 16.0 8.4 5.6 18.0 14 9 Q 4 0.19 1 TSXM 13050RS ● 50 41 40 22.0 10.4 6.3 20.0 18 11 Q 5 0.28 1 TSXM 13063RS ● 63 50 40 22.0 10.4 6.3 20.0 18 11 Q 6 0.50 1 TSXM 13080RS ● *80 55 50 27.0 12.4 7.0 22.0 20 14 Q 7 0.92 1 TSXM 13100RS ● 100 70 50 32.0 14.4 8.0 32.0 46 Q Q 8 1.36 3 TSXM 13125RS ● 125 80 63 40.0 16.4 9.0 29.0 52 29 Q 10 2.57 1 TSXM 13160RS ● 160 130 63 40.0 16.4 9.0 29.0 90 Q Q 12 5.02 5* TSXM 13200RS ● 200 160 63 60.0 25.7 14.0 35.0 135 Q Q 16 6.32 5 TSXM 13250RS ● 250 180 63 60.0 25.7 14.0 35.0 160 Q Q 20 9.42 5 TSXM 13315RS ● 315 240 63 60.0 25.7 14.0 35.0 230 Q Q 24 16.37 6 TSXM 13080R ● *80 55 50 25.4 9.5 6.0 25.0 20 14 Q 7 0.93 1 TSXM 13100R ● *100 70 63 31.75 12.7 8.0 32.0 46 27 18 8 1.90 2 TSXM 13125R ● 125 80 63 38.1 15.9 10.0 35.5 55 30 Q 10 2.62 1 TSXM 13160R ● 160 100 63 50.8 19.1 11.0 38.0 72 Q Q 12 4.22 4 TSXM 13200R ● 200 160 63 47.625 25.4 14.0 35.0 135 Q Q 16 6.48 5 TSXM 13250R ● 250 180 63 47.625 25.4 14.0 35.0 160 Q Q 20 9.68 5 TSXM 13315R ● 315 240 63 47.625 25.4 14.0 35.0 230 Q Q 24 16.63 6 Inserts are sold separately. Check the collet mounting size (DCB) when selecting the cutter. For securing the ø80mm and ø100mm cutters to the arbors marked with *, use a JIS B1176 hexagonal socket bolt (ø80: M12 x 30 to 35mm, ø100: M16 x 40 to 45mm). Identification Code TSX M 13 100 R S Cutter Series Fine Pitch Insert Size Cutter Dia. Feed Metric Direction Bore Parts Screw Integrated Detachable WrenchWrenchHandle GripBit Seat Anti-seizureCream Applicable Cutter Nm TSXM 13040RS TSXM 13050RS TSXM 13063RSTSXM 13080RS Q HPS1015 TRB15IP Q TSXM 13100RS TSXM 13125RS TSXM 13160RS TSXM 13200RSTSXM 13250RS BFTX03510IP 3.0 TRDR15IP Q Q TSXS13R SUMI-P TSXM 13315RS TSXM 13080R TSXM 13100RTSXM 13125R Q HPS1015 TRB15IP Q TSXM 13160R TSXM 13200RTSXM 13250R TRDR15IP Q Q TSXS13R TSXM 13315R H116 N m Recommended Tightening Torque (N·m) ● mark: Standard stocked item (new product/expanded item)
