ACP100 ACP200 ACP300 ACK200 ACK300 ACM200 ACM300 12.6 High-speedCast IronNon-ferrousMetalChamferingGroove /T-SlotR / 3DProfilingRadiusMulti-PurposeHigh FeedShoulderMillingFace MillingMillingCutters SEC-Sumi Dual Mill TSX 13000R(S) Type Steel Stainless Steel Cast Iron Exotic Alloy Insert  Dimensions (mm) Grade Coated Carbide High-speed / Light K Process General-purpose K Roughing K Nose Cat. No. Radius Fig RE LNEX 130604PNER-L ● ● ● ● ● ● 0.4 1LNEX 130608PNER-L●●●●●●0.81Fig 1 RE H LNEX 130612PNER-L ● ● ● ● 1.2 1 LNEX 130616PNER-L ● ● ● ● 1.6 1 LNEX 130620PNER-L ● ● ● ● 2.0 1 LNEX 130624PNER-L ● ● ● ● 2.4 1 LNEX 130632PNER-L ● ● ● ● 3.2 1 LNEX 130604PNER-G ● ● ● ● ● ● ● 0.4 1 LNEX 130608PNER-G ● ● ● ● ● ● ● 0.8 1 LNEX 130612PNER-G ● ● ● ● ● ● ● 1.2 1 LNEX 130616PNER-G ● ● ● ● ● ● ● 1.6 1 LNEX 130620PNER-G ● ● ● ● ● ● ● 2.0 1 13 6.4 LNEX 130624PNER-G ● ● ● ● ● ● ● 2.4 1 LNEX 130632PNER-G ● ● ● ● ● ● ● 3.2 1 LNEX 130604PNER-H ● ● ● ● 0.4 1 LNEX 130608PNER-H ● ● ● ● 0.8 1 LNEX 130612PNER-H ● ● ● ● 1.2 1 LNEX 130616PNER-H ● ● ● ● 1.6 1 LNEX 130620PNER-H ● ● ● ● 2.0 1 LNEX 130624PNER-H ● ● ● ● 2.4 1 LNEX 130632PNER-H ● ● ● ● 3.2 1 Recommended Cutting Conditions ISO Work Material Hardness Cutting Speed vc (m/min) Feed Rate fz (mm/t) InsertMin. - Optimum - Max.Min. - Optimum - Max.Grade 180 to 280 HB 150 - 225 - 300 0.10 - 0.30 - 0.40 ACP100 Carbon Steel P > 280HB 75 - 150 - 230 0.10 - 0.30 - 0.40 ACP200 Alloy Steel 180 to 280 HB 100 - 175 - 250 0.10 - 0.25 - 0.35 ACP300 Stainless 220 to 280 HB 90 - 135 - 180 0.10 - 0.20 - 0.30 ACM200 M Steel > 280HB 75 - 125 - 170 0.10 - 0.20 - 0.30 ACM300 K Cast Iron/Ductile Cast Iron 250HB 150 - 175 - 250 0.10 - 0.30 - 0.40 ACK200ACK300 S Exotic Alloy Q 30 - 60 - 90 0.10 - 0.15 - 0.20 ACM200ACM300 Note · The above recommended cutting conditions may require adjustment depending on machine rigidity and work rigidity. · The above figures are guidelines for use with BT50 machine tools. ● mark: Standard stocked item (new product/expanded item) H115
