High-speedCast IronNon-ferrousMetalChamferingGroove /T-SlotR / 3DProfilingRadiusMulti-PurposeHigh FeedShoulderMillingFace MillingMillingCutters SEC-WaveMill WEZ Type ■ Ramping / Helical Milling Upper Limits Ramping Flat bottom machining Machining with prepared hole Pitch Pitch RMPX ap DC DC DC H Work Dia. Work Dia. WEZ11 Type Flat bottom machining Machining with prepared hole Tool Dia. Max. Ramping Angle DC RMPX (°) Max. Machining Dia. Maximum Pitch Min. Machining Dia. Maximum Pitch Min. Machining Dia. Maximum Pitch (mm) (mm/rev) (mm) (mm/rev) (mm) (mm/rev) 14 13.2 25.3 8.4 23.1 5.9 19.0 1.9 16 10.5 29.3 7.6 27.0 5.6 21.7 1.5 18 8.1 33.3 6.7 30.9 5.0 25.2 1.4 20 6.5 37.3 6.0 34.9 4.6 29.1 1.3 22 5.3 41.3 5.4 38.8 4.3 32.9 1.3 25 4.1 47.3 4.8 44.8 3.9 38.9 1.3 28 3.4 53.3 4.4 50.7 3.6 44.9 1.3 30 3.0 57.3 4.2 54.7 3.5 48.8 1.3 32 2.7 61.3 4.0 58.7 3.3 52.8 1.2 35 2.3 67.3 3.8 64.6 3.1 58.8 1.2 40 1.8 77.3 3.4 74.6 2.9 68.8 1.2 50 1.2 97.3 3.0 94.6 2.6 88.8 1.1 63 0.8 123.3 2.8 120.5 2.5 114.7 1.1 WEZ17 Type Flat bottom machining Machining with prepared hole Tool Dia. Max. Ramping Angle DC RMPX (°) Max. Machining Dia. Maximum Pitch Min. Machining Dia. Maximum Pitch Min. Machining Dia. Maximum Pitch (mm) (mm/rev) (mm) (mm/rev) (mm) (mm/rev) 25 10.8 47.3 13.0 41.0 8.3 33.1 1.8 28 8.1 53.3 11.1 46.9 7.5 39.0 1.8 30 7.0 57.3 10.2 50.9 7.0 43.0 1.8 32 6.1 61.3 9.5 54.9 6.7 47.0 1.7 35 5.1 67.3 8.7 60.8 6.2 53.0 1.7 40 4.0 77.3 7.7 70.8 5.7 63.0 1.7 50 2.5 97.3 6.5 90.7 5.0 83.0 1.6 63 1.8 123.3 5.6 116.7 4.5 109.0 1.6 *The table above shows values with nose radius 0.8mm. ■ Plunge Cutting Upper Limit ae Max. ae (mm) WEZ11 Type 3 WEZ17 Type 5 H57
