Milling CuttersFace MillingShoulde rMillingHigh FeedMulti-PurposeRadiusR / 3DProfilingGroove /T-SlotChamferingNon-ferrousMetalHigh-speedCast Iron Axial Depth of Cut ap (mm) Combined Force (N) SEC-Sumi Dual Mill DGC Type ■ General Features SEC-Sumi Dual Mill DGC Type employs double-sided inserts with up to 16 corners for excellent economy. This is a general-purpose cutter featuring high cutting edge strength for high efficiency milling and a low-burr chipbreaker design that provides high machined surface quality. ONMT / ONET Type H ■ Features TdaUfhoonpeurdbtiDOomleGN1p-C6MsroiTdcTvyoe/epOdrdneNSeeiENnrcsTsoMenctTryoat/pnmSleiNbnys.ee.EuTupseindcludes (Double-sided, 16 Corners) SNMT / SNET Type(Double-sided, 8 Corners) ● Same cutting performance as single-sided inserts plus superior economy Achieves levels of cutting edge sharpness and machined surface quality equivalent to single-sided cutters at a maximum depth of cut of ap = 3mm. ● Recommended Cutting Conditions for General Steel ● Comparison of Cutting Force 6.0 3,000 Equivalent Level of Cutting Force 5.0 WGX Type / WGC Type Higher Efficiency 2,000 4.0 3.0 SNMT 13T6ANER 1,000 2.0 DGC Type 1.0 ONMT 05T6ANER 0 DGC Type DGC Type WGC Type (SNMT) (ONMT) 0 0.1 0.2 0.3 0.4 0.5 Work Material: SCM435 Tool: ø100 Feed Rate per Tooth fz (mm/t) Cutting Conditions: vc = 200m/min, fz = 0.3mm/t, ap = 3mm, ae = 85mm ● Common Body Features Two types of inserts can be used with a single body depending on the milling application, to help reduce tool costs. Use two types of insert for different applications Seat protects the body SNMT / SNET Type ONMT / ONET Type · Stronger than single-sided cutters · More economical double-sided · Economical double-sided design gives double the design with 16 corners number of cutting edges of standard inserts (Maximum depth of cut = 3.0mm) (Maximum depth of cut = 6.0mm) ● Choose a tool to suit your application from a comprehensive lineup Cutter Diameter: ø40mm to ø250mm Cutter Diameter: ø50mm to ø250mm Cutter Diameter: ø50mm to ø250mm Cutter Diameter: ø40mm to ø63mm No. of Teeth: 3 to 10 No. of Teeth: 4 to 14 No. of Teeth: 5 to 18 No. of Teeth: 3 to 4 Mounting: Metric/Inch Mounting: Metric/Inch Mounting: Metric/Inch Mounting: Metric DGC 13000R(S) DGCM 13000R(S) DGC F 13000R(S) DGC 13000 EW Standard Pitch Fine Pitch Extra Fine Pitch Endmill Type H28
