Stock HF WF S PDY T1500A T130A BH PDY Tools Threading SEC-Threading Tools SEC-External Threading Tool Holders STE Type Screw-on / Lever Lock External for External Diameter STE Fig 1 Metric ThreadWhitworth Thread Unified Thread External Threading Taper Thread for Pipe 22 LF -10° F Holder Parts  Dimensions (mm) Cat. No. Height Width Overall Length Cutting EdgeDistanceCutting EdgeHeightFig Flat Screw Wrench H B LF WF HF Nm STE R1212STE R1616 ● 12●16 12 100 161610020 1216 11BFTX03508 2.0 TRX10 Fig 1 (TME300R only) PDX PDX RE RE IC *( TME350R TME400R and are ) *ø3.81 ø4.76. Close-up of Close-up of Cutting Edge Cutting Edge Insert ( Cermet) Dimensions (mm) Type Cat. No. Reference Cat. PitchNo.mmThreads/Inch Nose Radius X direction Y direction Inscribed Circle Thickness WiperREPDXPDYICSEdgeApplicableHolderFig TME 100R 16ER100ISO-TE 1.00 Q ●● 0.11 0.8 1.2 9.525 3.65 Yes 1 TME 125R 16ER125ISO-TE 1.25 Q ●● 0.15 0.8 1.2 9.525 3.65 Yes 1 TME 150R 16ER150ISO-TE 1.50 Q ●● 0.19 1.0 1.2 9.525 3.65 Yes 1 60° TME 175R 16ER175ISO-TE 1.75 Q ●● 0.22 1.2 1.2 9.525 3.65 Yes 1 Metric TME 200R 16ER200ISO-TE 2.00 Q ●● 0.26 1.4 1.2 9.525 3.65 Yes 1 Thread TME 250R 16ER250ISO-TE 2.50 Q ●● 0.33 1.4 1.2 9.525 3.65 Yes 1 TME 300R 16ER300ISO-TE 3.00 Q ●● 0.40 1.8 1.2 9.525 3.65 Yes 1 TME 1020R 16ER102060-TE 1.00 to 2.00 24 to 12 ● ● 0.11 1.1 1.2 9.525 3.65 No 1 TME 1530R 16ER153060-TE 1.50 to 3.00 16 to 8 ●● 0.19 1.6 1.0 9.525 3.65 No 1 55° TWE 1410R 16ER141055-TE Q 14 to 10 ● 0.21 1.4 1.2 9.525 3.65 No 1 Whitworth Thread TWE 2416R 16ER241655-TE Q 24 to 16 ● 0.11 1.1 1.2 9.525 3.65 No STE R1212 1 TUE 24R 16ER24UN-TE Q 24 ● 0.12 0.8 1.2 9.525 3.65 Yes STE R1616 1 TUE 20R 16ER20UN-TE Q 20 0.15 0.8 1.2 9.525 3.65 Yes 1 60° TUE 18R 16ER18UN-TE Q 18 0.17 1.0 1.2 9.525 3.65 Yes 1 Unified TUE 16R 16ER16UN-TE Q 16 ● 0.20 1.2 1.2 9.525 3.65 Yes 1 Thread TUE 14R 16ER14UN-TE Q 14 ● 0.23 1.2 1.2 9.525 3.65 Yes 1 TUE 12R 16ER12UN-TE Q 12 ● 0.28 1.4 1.2 9.525 3.65 Yes 1 TUE 08R 16ER08UN-TE Q 8 0.43 1.8 1.2 9.525 3.65 Yes 1 55° TPE 28R 16ER28BSPT-TE Q 28 0.09 0.9 0.7 9.525 3.65 Yes 1 Taper TPE 19R 16ER19BSPT-TE Q 19 ● 0.15 0.9 0.7 9.525 3.65 Yes 1 Thread for TPE 14R 16ER14BSPT-TE Q 14 ● 0.22 1.6 1.2 9.525 3.65 Yes 1 Pipe TPE 11R 16ER11BSPT-TE Q 11 ● 0.29 1.6 1.2 9.525 3.65 Yes 1 For these inserts, only LTE/STE Type holders can be used. N m Recommended Tightening Torque (N·m) F95
