Каталог Stellram токарный инструмент - страница 137

Заказ инструмента: http://steelcam.org T Style 8 (343) 382-52-03 | sales@sverla-ekb.ru Turning Inserts r s Turning Inserts TNMG m 4T Geometry d h 60° I EDP ISO Description Grade Dimensions (mm) Material Application d I s r h 032814 TNMG220404E-4T NL250 12,70 22,00 4,76 0,40 5,16 Roughing 032815 TNMG220404E-4T NL300 12,70 22,00 4,76 0,40 5,16 Roughing 032816 TNMG220404E-4T NL400 12,70 22,00 4,76 0,40 5,16 Roughing 032817 TNMG220404E-4T NL920 12,70 22,00 4,76 0,40 5,16 Roughing 032818 TNMG220408E-4T NL250 12,70 22,00 4,76 0,80 5,16 Roughing 032819 TNMG220408E-4T NL300 12,70 22,00 4,76 0,80 5,16 Roughing 032820 TNMG220408E-4T NL400 12,70 22,00 4,76 0,80 5,16 Roughing 032821 TNMG220408E-4T NL920 12,70 22,00 4,76 0,80 5,16 Roughing 032822 TNMG220412E-4T NL250 12,70 22,00 4,76 1,20 5,16 Roughing 032823 TNMG220412E-4T NL300 12,70 22,00 4,76 1,20 5,16 Roughing 032824 TNMG220412E-4T NL400 12,70 22,00 4,76 1,20 5,16 Roughing 032825 TNMG220412E-4T NL920 12,70 22,00 4,76 1,20 5,16 Roughing 032826 TNMG220416E-4T NL250 12,70 22,00 4,76 1,60 5,16 Roughing 032827 TNMG220416E-4T NL300 12,70 22,00 4,76 1,60 5,16 Roughing 032828 TNMG220416E-4T NL400 12,70 22,00 4,76 1,60 5,16 Roughing 032829 TNMG220416E-4T NL920 12,70 22,00 4,76 1,60 5,16 Roughing 032830 TNMG220432E-4T NL300 12,70 22,00 4,76 3,20 5,16 Roughing For Toolholders External: see pages C139 - C140 | Internal: see page C141 Material Guide – Key to Recommended Inserts Material Designation P Unalloyed Steels P Alloyed Steels M Stainless Steels M PH Stainless K Cast Irons N Aluminum & Alloys S High Temp. Alloys H Hard Materials C136 www.kennametal.com
