METRIC Multi-Carb 35° POS 7 9 11 LF APMX DC DCON 66M • RE 66MCR METRIC SERIES TOLERANCES (mm) mm EDP NO. • Heavy core and rigid DC = +0,000/–0,050 NON- design allow for DCON = h 6 CUTTING straight walls CUTTING LENGTH OVERALL SHANK CORNER CENTER NO. OF TI-NAMITE-X • High flute count design RE = +0,000/–0,050 DIAMETER OF CUT LENGTH DIAMETER RADIUS DIAMETER FLUTES results in smoother DC APMX LF DCON RE NCD cutting performance STEELS 6,0 19,0 63,0 6,0 – 1,63 7 46620 and enhanced tool life in precise finishing 8,0 20,0 63,0 8,0 0,5 1,63 7 46627 applications STAINLESS STEELS 6,0 19,0 63,0 6,0 1,0 1,63 7 46628 • Enhanced corner geometry with tight CAST IRON 8,0 20,0 63,0 8,0 – 1,78 7 46621 tolerance corner radii HIGH TEMP ALLOYS 8,0 20,0 63,0 8,0 0,5 1,78 7 46629 • Recommended for 8,0 20,0 63,0 8,0 1,0 1,78 7 46630 materials ≤ 45 HRc TITANIUM (≤ 420 Bhn) 8,0 20,0 63,0 8,0 1,5 1,78 7 46631 HARDENED STEELS 10,0 22,0 75,0 10,0 – 2,03 7 46622 10,0 22,0 75,0 10,0 0,5 2,03 7 46632 For patent information visit 10,0 22,0 75,0 10,0 1,0 2,03 7 46633 www.ksptpatents.com 10,0 22,0 75,0 10,0 1,5 2,03 7 46634 10,0 22,0 75,0 10,0 2,0 2,03 7 46635 12,0 26,0 83,0 12,0 – 3,45 9 46623 12,0 26,0 83,0 12,0 1,0 3,45 9 46636 12,0 26,0 83,0 12,0 1,5 3,45 9 46637 12,0 26,0 83,0 12,0 2,0 3,45 9 46638 12,0 26,0 83,0 12,0 2,5 3,45 9 46639 12,0 26,0 83,0 12,0 3,0 3,45 9 46640 16,0 32,0 92,0 16,0 – 2,92 9 46624 16,0 32,0 92,0 16,0 1,0 2,92 9 46641 16,0 32,0 92,0 16,0 1,5 2,92 9 46642 16,0 32,0 92,0 16,0 2,0 2,92 9 46643 16,0 32,0 92,0 16,0 2,5 2,92 9 46644 16,0 32,0 92,0 16,0 3,0 2,92 9 46645 16,0 32,0 92,0 16,0 4,0 2,92 9 46646 20,0 38,0 104,0 20,0 – 4,57 11 46625 20,0 38,0 104,0 20,0 1,0 4,57 11 46647 20,0 38,0 104,0 20,0 1,5 4,57 11 46648 20,0 38,0 104,0 20,0 2,0 4,57 11 46649 20,0 38,0 104,0 20,0 2,5 4,57 11 46650 20,0 38,0 104,0 20,0 3,0 4,57 11 46651 20,0 38,0 104,0 20,0 4,0 4,57 11 46652 continued on next page Neck Option Available 93 END MILLS www.kyocera-sgstool.com END MILLS
