FRACTIONAL & METRIC Z-Carb-MD 45° NEG 42° 4 ≠ LF LU DC DCON RE APMX DN ZD1CR FRACTIONAL SERIES TOLERANCES (inch) inch EDP NO. • The original Z-Carb 1/8–1/4 DIAMETER CUTTING LENGTH OVERALL SHANK REACH NECK CORNER Ti-NAMITE-X design with negative DC = +0.0000/–0.0012 DIAMETER OF CUT LENGTH DIAMETER LU DIAMETER RADIUS rake, heavy core, and DC APMX LF DCON DN RE higher helix for strength DCON = h 6 and shearing of hard RE = +0.0000/–0.0020 1/8 5/32 2-1/2 1/4 1/2 .110 .010 36780 mold & die materials 3/16 7/32 2-1/2 1/4 3/4 .172 .020 36781 • Unequal flute spacing >1/4–3/8 DIAMETER helps to disrupt the DC = +0.0000/–0.0016 1/4 9/32 2-1/2 1/4 3/4 .235 .020 36782 rhythmic pattern DCON = h 6 5/16 13/32 2-1/2 5/16 1 .297 .040 36783 created by the cutting RE = +0.0000/–0.0020 3/8 15/32 2-1/2 3/8 1 .360 .040 36784 edge helping to suppress damaging >3/8–3/4 DIAMETER 7/16 9/16 2-3/4 7/16 1 .422 .040 36785 harmonics DC = +0.0000/–0.0020 1/2 5/8 3 1/2 1-1/4 .485 .040 36786 • Enhanced corner DCON = h 6 geometry with tight 1/2 5/8 4-1/2 1/2 2-1/4 .485 .040 36787 tolerance corner radii RE = +0.0000/–0.0020 5/8 3/4 3-1/2 5/8 1-1/2 .610 .040 36788 • Recommended for 5/8 3/4 4-1/2 5/8 2-1/4 .610 .040 36789 materials 35-60HRc HARDENED STEELS (327 to 654 Bhn) 5/8 3/4 5-1/2 5/8 3-1/4 .610 .040 36790 3/4 15/16 4 3/4 1-3/4 .735 .060 36791 For patent 3/4 15/16 4-1/2 3/4 2-1/4 .735 .060 36792 information visit www.ksptpatents.com 3/4 15/16 5-1/2 3/4 3-1/4 .735 .060 36793 LF LU DC DCON RE APMX DN ZD1MCR METRIC SERIES TOLERANCES (mm) mm EDP NO. • The original Z-Carb 3–6 DIAMETER CUTTING LENGTH OVERALL SHANK REACH NECK CORNER Ti-NAMITE-X design with negative DC = +0,000/–0,030 DIAMETER OF CUT LENGTH DIAMETER LU DIAMETER RADIUS rake, heavy core, and DC APMX LF DCON DN RE higher helix for strength DCON = h 6 and shearing of hard RE = +0,000/–0,050 3,0 4,0 57,0 6,0 15,0 2,62 0,2 46560 mold & die materials 4,0 5,0 57,0 6,0 15,0 3,61 0,3 46561 • Unequal flute spacing >6–10 DIAMETER helps to disrupt the DC = +0,000/–0,040 5,0 6,0 57,0 6,0 15,0 4,60 0,5 46562 rhythmic pattern DCON = h 6 6,0 7,0 57,0 6,0 15,0 5,61 1,0 46563 created by the cutting RE = +0,000/–0,050 8,0 10,0 63,0 8,0 25,0 7,62 1,0 46564 edge helping to suppress damaging >10–20 DIAMETER 10,0 12,0 72,0 10,0 30,0 9,60 1,0 46565 harmonics DC = +0,000/–0,050 12,0 15,0 83,0 12,0 35,0 11,61 1,0 46566 • Enhanced corner DCON = h 6 geometry with tight 16,0 20,0 92,0 16,0 45,0 15,60 1,5 46567 tolerance corner radii RE = +0,000/–0,050 20,0 24,0 104,0 20,0 55,0 19,61 2,0 46568 • Recommended for materials 35-60HRc HARDENED STEELS (327 to 654 Bhn) For patent information visit www.ksptpatents.com 61 END MILLS www.kyocera-sgstool.com END MILLS
