METRIC
Z-Carb
POS

4
≠


TOLERANCES (mm)
3–6 DIAMETER
Z1MB
METRIC SERIES
D1 = +0,000/–0,030
D2 = h6 mm EDP NO. • Unequal helix design
CUTTING LENGTH OVERALL SHANK Ti-NAMITE-X JetStream aids in damaging
>6–10 DIAMETER DIAMETER OF CUT LENGTH DIAMETER (TX) harmonics by changing
D1 = +0,000/–0,040 D1 L2 L1 D2 the angle at which each
cutting edge enters and
D2 = h6 3,0 8,0 57,0 6,0 46354 – exits the material
>10–25 DIAMETER 4,0 11,0 57,0 6,0 46355 – • Unequal flute spacing
5,0 13,0 57,0 6,0 46356 – helps to disrupt the
D1 = +0,000/–0,050
rhythmic pattern
D2 = h6 6,0 13,0 57,0 6,0 46343 – created by the cutting
8,0 19,0 63,0 8,0 46344 – edge helping to
suppress damaging
STEELS 10,0 22,0 72,0 10,0 46345 – harmonics
12,0 26,0 83,0 12,0 46346 – • Optimal material
STAINLESS STEELS removal rates through
14,0 26,0 83,0 14,0 46347 46518 increased feed and
CAST IRON
16,0 32,0 92,0 16,0 46348 46519 depths of cut
• Ball nose design ideal
HIGH TEMP ALLOYS 18,0 32,0 92,0 18,0 46349 46520 for finishing operations
TITANIUM
20,0 38,0 104,0 20,0 46350 46521 in complex workpieces
25,0 38,0 104,0 25,0 46351 46522 • Recommended for
HARDENED STEELS materials ≤ 45 HRc
(≤ 420 Bhn)
For patent
information visit
www.ksptpatents.com


51
END MILLS
www.kyocera-sgstool.com END MILLS
