| 30° | 15° | POS | 3 | ||||||
| M3B • 1 .5 | .xD | A | PMX | LU | LF | DCON | |||
| . 20xD | . | DC | DN | TOLERANCES(inc | |||||
| FRACTIONAL SERIES | RE | .010–.120DIAMET DC =+0.000/–0.00 | |||||||
| • Three flute design | inc | h | EDP | NO. | DCON =h6 | ||||
| features improved chip space over four flutes | CUTTING DIAMETER | SHANK DIAMETER | LENGTH OF CUT | REACH | NECK DIAMETER | OVERALL LENGTH | UNCOATED | TI-NAMITE-A | |
| and increased strength | DC | DCON | APMX | LU | DN | LF | (AlTiN) | STEELS | |
| and feed capability over two flutes | 0.010 | 1/8 | 0.015 | 0.200 | 0.009 | 2-1/2 | 09408 | 03940 | STAINLESS STEELS |
| . • Proprietary coating | 0.015 | 1/8 | 0.023 | 0.300 | 0.014 | 2-1/2 | 09415 | 03941 | |
| allows for superior chip | 0.020 | 1/8 | 0.030 | 0.400 | 0.018 | 2-1/2 | 09422 | 03942 | CAST IRON |
| flow, driving industry leading productivity | 0.025 | 1/8 | 0.038 | 0.500 | 0.023 | 2-1/2 | 09429 | 03943 | HIGH TEMP ALLOYS |
| and value, even at low sindle seeds | 0.030 | 1/8 | 0.045 | 0.600 | 0.028 | 2-1/2 | 09436 | 03944 | TITANIUM |
| p p. • High performance | 0.031 | 1/8 | 0.047 | 0.620 | 0.029 | 2-1/2 | 09443 | 03945 | |
| carbide substrate | 0.035 | 1/8 | 0.053 | 0.700 | 0.032 | 2-1/2 | 09450 | 03946 | HARDENED STEELS |
| designed specifically for Micro Tool applications. | 0.040 | 1/8 | 0.060 | 0.800 | 0.037 | 2-1/2 | 09457 | 03947 | NON-FERROUS |
| • Broad portfolio, offering | 0.045 | 1/8 | 0.068 | 0.900 | 0.042 | 2-1/2 | 09464 | 03948 | PLASTICS/COMPOSITES |
| consistent lengths of cut, to ensure alication | 0.047 | 1/8 | 0.071 | 0.940 | 0.044 | 2-1/2 | 09471 | 03949 | |
| pp demands are met. | 0.050 | 1/8 | 0.075 | 1.000 | 0.047 | 2-1/2 | 09478 | 03950 | |
| • Advanced geometries | 0.055 | 1/8 | 0.083 | 1.100 | 0.051 | 2-1/2 | 09485 | 03951 | |
| that extend tool life, reduce chatter, cut cycle | 0.060 | 1/8 | 0.090 | 1.200 | 0.056 | 2-1/2 | 09492 | 03952 | |
| times, and improve part | 0.062 | 1/8 | 0.093 | 1.240 | 0.058 | 2-1/2 | 09499 | 03953 | |
| quality. • All tools in stock to | 0.065 | 1/8 | 0.098 | 1.300 | 0.061 | 3 | 09506 | 03954 | |
| meet customer order | 0.070 | 1/8 | 0.105 | 1.400 | 0.065 | 3 | 09513 | 03955 | |
| requirements. | 0.075 | 1/8 | 0.113 | 1.500 | 0.070 | 3 | 09520 | 03956 | |
| • All micro tools are manufactured in | 0.078 | 1/8 | 0.117 | 1.560 | 0.073 | 3 | 09527 | 03957 | |
| accordance with the KSPT ISO tifid | 0.080 | 1/8 | 0.120 | 1.600 | 0.075 | 3 | 09534 | 03958 | |
| cere quality procedures. | 0.085 | 1/8 | 0.128 | 1.700 | 0.079 | 3 | 09541 | 03959 | |
| 0.090 | 1/8 | 0.135 | 1.800 | 0.084 | 3 | 09548 | 03960 | ||
| 0.093 | 1/8 | 0.140 | 1.860 | 0.087 | 3 | 09555 | 03961 | ||
| 0.095 | 1/8 | 0.143 | 1.900 | 0.089 | 3 | 09562 | 03962 | ||
| 0.100 | 1/8 | 0.150 | 2.000 | 0.094 | 4 | 09569 | 03963 | ||
| 0.110 | 1/8 | 0.165 | 2.200 | 0.103 | 4 | 09576 | 03964 | ||
| 0.115 | 1/8 | 0.173 | 2.300 | 0.108 | 4 | 09583 | 03965 | ||
| 0.120 | 1/8 | 0.180 | 2.400 | 0.112 | 4 | 09590 | 03966 |
RE = 1/2 Cutting Diameter (DC)
