| Series M032 | Ae | Ap Ae | Vc | DC • mm | |||||
| Metric | Hardness | Ae x DC | Ap x DC | (m/min) | 1 | 2 | 3 | ||
| Profile | 102 | RPM | 32475 | 16238 | 10825 | ||||
| ≤ 0.25 | ≤ 1 | (82-123) | Fz | 0.0026 | 0.0052 | 0.0077 | |||
| Feed (ipm) | 251 | 251 | 251 | ||||||
| STAINLESS STEELS | ≤ 275 Bhn | Slot | 75 | RPM | 23751 | 11875 | 7917 | ||
| M (DIFFICULT) | or | 1 | ≤ .5 | Fz | 0.0021 | 0.0043 | 0.0064 | ||
| 304, 304L, 316, 316L | ≤ 28 HRc | (60-90) | Feed (ipm) | 152 | 152 | 152 | |||
| Finish | 184 | RPM | 58650 | 29325 | 19550 | ||||
| ≤ .02 | 1 | (148221) | Fz | 0.0040 | 0.0079 | 0.0119 | |||
| - | Feed (ipm) | 699 | 699 | 699 | |||||
| Profile | 94 | RPM | 30052 | 15026 | 10017 | ||||
| ≤ 0.25 | ≤ 1 | (76-113) | Fz | 0.0025 | 0.0051 | 0.0076 | |||
| Feed (ipm) | 229 | 229 | 229 | ||||||
| STAINLESS STEELS | ≤ 325 Bhn | Slot | 69 | RPM | 21812 | 10906 | 7271 | ||
| M (PH) 13-8 PH, 15-5 PH, | or | 1 | ≤ .5 | (5582) | Fz | 0.0021 | 0.0043 | 0.0064 | |
| 17-4 PH, Custom 450 | ≤ 35 HRc | - | Feed (ipm) | 140 | 140 | 140 | |||
| Finish | 169 | RPM | 53803 | 26901 | 17934 | ||||
| ≤ .02 | 1 | Fz | 0.0040 | 0.0080 | 0.0120 | ||||
| (135-203) | Feed (ipm) | 648 | 648 | 648 | |||||
| Profile | 61 | RPM | 19388 | 9694 | 6463 | ||||
| ≤ 0.5 | ≤ 1.5 | (4973) | Fz | 0.0022 | 0.0045 | 0.0067 | |||
| SUPER ALLOYS | - | Feed (ipm) | 130 | 130 | 130 | ||||
| (NICKEL, COBALT, | ≤ 400 Bhn | Slot | 44 | RPM | 14057 | 7028 | 4686 | ||
| S IRON BASE) Inconel 718, X-750, | or | 1 | ≤ 1 | 3553 | Fz | 0.0019 | 0.0039 | 0.0058 | |
| Incoloy, Waspaloy, | ≤ 43 HRc | (-) | Feed (ipm) | 81 | 81 | 81 | |||
| Hastelloy, Rene | Finish | 110 | RPM | 34899 | 17449 | 11633 | |||
| ≤ .02 | 1 | (88132) | Fz | 0.0035 | 0.0070 | 0.0106 | |||
| - | Feed (ipm) | 368 | 368 | 368 | |||||
| Profile | 75 | RPM | 23751 | 11875 | 7917 | ||||
| ≤ 0.5 | ≤ 1.5 | Fz | 0.0022 | 0.0045 | 0.0067 | ||||
| (60-90) | Feed (ipm) | 160 | 160 | 160 | |||||
| TITANIUM ALLOYS Pure Titanium, | ≤ 350 Bhn | Slot | 55 | RPM | 17449 | 8725 | 5816 | ||
| S Ti6Al4V, | or | 1 | ≤ 1 | Fz | 0.0019 | 0.0038 | 0.0057 | ||
| Ti6Al2Sn4Zr2Mo, Ti4Al4Mo2Sn0.5Si | ≤ 38 HRc | (44-66) | Feed (ipm) | 99 | 99 | 99 | |||
| Finish | 134 | RPM | 42654 | 21327 | 14218 | ||||
| ≤ .02 | 1 | Fz | 0.0036 | 0.0071 | 0.0107 | ||||
| (107-161) | Feed (ipm) | 457 | 457 | 457 |
Bhn (Brinell) HRc (Rockwell C) rpm = (Vc x 1000) / (DC x 3.14) mm/min = Fz x 3 x rpm (Fz x 3 x max available rpm when recommendation exceeds machine limit) reduce speed and feed for materials harder than listed refer to the KYOCERA SGS Tool Wizard® for complete technical information (www.kyocera-sgstool.com)
