Grinding Disks / Dressers Tool grinding wheel for double grinders Design and use:See product information on previous page EK NK SiC FormA Note: Other dimensions, grain sizes and composites for special materials available on request D H 465100 Special fused alumina (EK pink) for tool grinding HSS 465150 Normal corundum (NC) for steel coarse T 465160 Normal corundum (NC) for steel fine 465200 Silicon carbide (SIC) for hard metal Form A without recess D×T×Hmm 465100 465150 465160 465200 465100 465150 465160 465200Grit/hardnessGrit/hardnessGrit/hardnessGrit/hardness 125×20×32     80M 36P 60N 80J 150×20×32     80M 36P 60N 80J 150×25×51     80M 36P 60N 80J 175×20×32     80M 24P 60N 80J 175×25×32     80M 24Q 60N 80J 175×25×51     80M 24Q 60N 80J 200×25×32     80M 24Q 60N 80J 200×25×51     80M 24Q 60N 80J 200×32×51     80M 24Q 60N 80J 300×40×76     60M 24Q 60N 80J Tool grinding wheel Design:Size 100K = with special edge hardening (mainly for stylus grinders) EK DIN Form69139D Use: - for tool grinding on stationary mechanical tool grinders - for grinding of cutting tools like milling cutters, drills, broaches et al. 465900 Fused alumina (EK) for tool grinding Dmm 465900 Bore d mm Width Bmm Size a × bmm Grit/hardness 100  20 50 40 × 90 60/1J 100K  20 50 40 × 90 60/7J Grinding disk dresser Grinding disk dresserTETRABOR® 46 Design: Des4ig6n9:100 - exchangeable steel-section grinding wheel dresser Dresser of pure boron carbide, the hardest - on one axis with pressurised lubrication nipple, material following diamonds and boron nitride mounted in the dressing head - the spinning dresser made of hardened, U-shaped Use: Swedish steel profile teeth, which are very durable For economical dressing, profiling and and can be used until complete wear out 469150 sharpening of grinding wheels - lateral plate to protect against sparks andabrasive particles Note: 469300Dressing with soft pressure using only the edge!469300 469100 For disks upto x 300 mm 469100 complete with spinning top 469150 Spare spinning top 469320 469300 TETRABOR® dresser size 469100 469150 Roll  × width mm Total length 46915m0m grinding wheel  / max. widthmm 469320 Holder for TETRABOR® dresser 0   36 × 12 285 125-250/35155 × 24435250-500/60 Length × width × thicknessmm 469300 469320 2   55 × 50 435 250-500/100 75×12×6   Dressing rod Sharpener Design: Design and use: - diamond saving dresser filled with silicon carbide SiC - with soft polyurethane bonding SiC - with plastic sleeve and wooden handle - abrasive silicon carbide - for resharpening or uncovering of Use: fresh layers on diamonds cutting wheels For profiling and dressing of grinding disks - by cutting off thin slices from the sharpening file the external blunt diamonds are removed from the abrasive segment 469200 Silicon carbide 469380 Silicon carbide Thicknessmm 469200 Lengthmm Length × width × thicknessmm 469380 20  400 200×50×25  46/852 www.precitool.de
