Optical / Device Monitoring Basic element clamping system E1 Design: - base plate for the construction of small (type 0001) or medium size (type 0002) fixtures - marking out bores help to reproduce the reconstruction of modular fixtures in combination with exchangeable plates - material aluminium - surface hard coated - thread M6 - marking out bores x 12.5 mm - grid spacing 50 mm 396000 Base plate Type 396000 Dimensions Weightmmkg 0001  250 × 250 × 20 3.1 0002  500 × 400 × 20 10.2 0001 0002 Design: Design: - plate for reproducible construction of fixtures - material aluminium in modular design - surface hard coated - only the individual modules are stored, which - groove width 6.3 mm saves base plates and storage place - material aluminium Use: - surface hard coated For bridging grid spacings of base - thread M6 elements and for direct mounting - marking out bores x 12.5 mm of further components - grid spacing 25 mm 396001 SubplateType396001 396002 Strap M6DimensionsmmWeightkgType396002 Dimensionsmm 39Thread 0001  50 × 75 × 20 0.165 0001  20 × 10 × 100 M6 Design and use: Design and use: - material aluminium - material aluminium - surface hard coated - surface hard coated - groove width 6.3 mm - groove width 6.3 mm - to receive components - to bridge the grid spacings with 8 mm pin x of the base elements 396003 Strap with bore 396004 Strap with slot Type 396003 Dimensionsmm Bore xmm Type 396004 Dimensionsmm 0001  20 × 10 × 100 8 0001  20 × 10 × 100 Design and use: Design and use: - material aluminium - material aluminium - surface hard coated - surface hard coated - groove width 6.3 mm - groove width 6.3 mm - to bridge the grid spacings of the base ele- - for continuous attachment of ments and for simultaneous mounting components in 3 axial directions of components for continuous height - the strap is positioned over the adjustment via thread M12 × 1 bolts with x 20 mm and secured by means of a screw 396005 Strap M12 × 1 396006 Strap slotted Type 396005 Dimensionsmm Thread Type 396006 Dimensionsmm Bore xmm 0001  20 × 10 × 100 M12 × 1 0001  25 × 15 × 125 20 Design and use: Design and use: - material aluminium - material aluminium - surface hard coated - surface hard coated - groove width 6.3 mm - cylindrical base element to construct - mainly used in combination with fixtures on top of base elements exchangeable plate 396001 0001 to create very solid and extremely torsion-proof modules 396007 Strap M6 396008 Bolt, centre hole X 12.5 mm Type 396007 Dimensionsmm Thread Type 396008 xmm Lengthmm Thread 0001  20 × 20 × 58 M6 0001  20 100 M6 www.precitool.de 39/775
