Gauge Blocks / Gauges Feeler gauge accessories Thread cutting gauge Design: Design: Plastic holder with spring-supported clamp, - precision version purpose-built for feeler gauge strips 389300. - edges ground, surface fine ground Use: - for threads Whitworth 50° - metric threads 60° 389500 60° / 50° 389350 Blade holder Lengthmm 389350 Thread 38950055 135  60  Thread cutting gauge Thread cutting gauge Design: Design: - precision version - precision version - recesses neatly milled - for flat, trapezoidal and V-shaped threads 55° and 60° - for trapezoidal threads of 2 - 12 mm, pitch to DIN 103 - side angle 30°, with recess 30° 38 389550 trapezoid 389580 combined Pitchmm 389550 Type 389580 2 - 12  KGL  Grinding gauge Design and use: - for twist drills with a point angle of 118° - gauge angle 121° results in a twist drill angle of 118° - measuring range for twist drills up to 50 mm x 389720 for twist drills Type 389720 SPL  Measuring wedge Design: - special steel, polished, matt chromium-plated - scale lasered, knurled handle - ABS plastic, scale CNC-divided - resolution 0.1 mm Use: - for measuring gap dimensions 389810 Measuring wedge Measuring rangemm 389810 Dimensionsmm Weightg 0,5 - 7  124 ×   8 × 8 39 2,0 - 7  109 ×   8 × 8 38 0,5 - 11  153 × 12 × 8 62 0,5 - 11K  155 × 12 × 8 17 38/760 www.precitool.de
