Gauge Blocks / Gauges Extension module topdown Design: For composite top-down measurements Scope of delivery: - software PRECICOM topdown - double-sided calibration standard with certificate (for machine calibration) - 1x double stylus tip quick-release fastener - 2× 20.5 mm probe tip 38 388915 Precicom topdown module Type 388915 Design 0001  Module when ordering machine 0005  Retrofit kit Extension module Design: - combines the advantages of a round (rotary) table and a swivelling object holder - simplest roundness measurements - concentricity 2.5 μm - as standard on a special motorised Y-table with measuring system and 25 mm travel - as standard with manual three-jaw chuck - fully integrated into the Precicom software - absolutely torsion-resistant - inside-outside clamping - swing x over granite base 190 mm - roughness fully measurable on the x at circumference - CNC programmable - movement controllable via machine console provided with buttons and joystick - three integrated optical, incremental and contactless measuring systems 388917 Rotary swivelling table Type 388917 L×W×Hmm Y-travelmm Spindle pitchmm Swing angle Weightkg 0025  365 × 145 × 255 25 3 ±120° 30 38/756 www.precitool.de
