Gauge Blocks / Gauges Surface measuring device MarSurf Design: - handy roughness measuring device for mobile use - easy and intuitive menu navigation USB IP40 microSD RS 232 C - large, illuminated 4.3” TFT touch display - display rotatable - Start button simultaneously Home button for direct access to the start screen - data backup as TXT, X3P, CSV and PDF file - mains-free operation - over 1,200 measurements without charging - flexible thanks to removable feed unit - for all measuring positions - horizontal, vertical, overhead - with integrated, removable roughness standard - quick access to functions by favourites in the display - standards DIN-ISO/JIS/ASME/MOTIF selectable - setting unbalanced profile section levels for peak counting - tolerance monitoring - lock and/or password protection for device setting - date and time for recording Use: - roughness measurements on site directly at the workpiece - measuring in the production process - universal on the processing machine - in the incoming goods inspection Delivery: MarSurf PS10 basic unit, feed unit, standard feeler (according to norm), rechargeable battery (built-in), roughness standard (including Mahr calibration certificate), feeler protection, charger, 3 mains adapters, operating instructions, carrying case with shoulder strap, USB cable, extension cable feed unit, height adjustment (integrated) Functions: measuring unit ....................................................... metric/inch measuring principle .............................................. profile method feeler ....................................................................... inductive skid sensor, 2 µm feeler tips, measuring force approx. 0.7 mN parameters.............................................................. => DIN/ISO: Ra, Rq, Rz, Rmax, Rp, Rpk, Rv, Rk, Rvk, Mr1, Mr2, A1, A2, Vo, Rt, Rv, RPc, Rmr, RSm, Rsk, CR, CF, CL, R, AR, Rx ................................................................................. => JIS: Ra, Rq, Ry (corr. Rz), RzJIS, tp (corr. Rmr), RSm, RS................................................................................. => ASME: Rp, Rpm, RPc, Rsk, tp (corr. Rmr)38 ................................................................................. => MOTIF: R, AR, Rx, CR, CF, CL languages ............................................................... 17, of which 3 are Asian measuring range ................................................... 350 µm profile resolution ................................................... 8 nm filter*........................................................................ => Gaussian filter according to ISO 16610-21 ................................................................................. => special filter according to DIN EN ISO 13565-1 ................................................................................. => Is-filter according to DIN EN ISO 3274 (on-off-switchable) Cutoff Ic*................................................................. 0.25 mm / 0.8 mm / 2.5 mm / automatic traversing length Lt* ............................................. 1.5 mm / 4.8 mm / 15 mm / automatic / N × Lc, freely selectable traversing length (acc. to MOTIF) ........................ 1 mm / 2 mm / 4 mm / 8 mm / 12 mm / 16 mm shortened Cutoff* .................................................. selectable total measuring distance In* ................................ 1.25 mm / 4.0 mm / 12.5 mm number of the individual measuring sections* .. selectable from 1 to 16 calibration function ............................................... dynamic memory capacity ................................................... 3,900 profiles, 500,000 results, 1,500 PDF files, expandable with microSD card up to 32 GB dimensions ............................................................. H × W × D = 160 × 77 × 50 mm weight ..................................................................... 500 g battery .................................................................... Li-ion battery, 3.7 Volt, nominal capacity 11.6 Wh interfaces ............................................................... USB device, MarConnect (RS 232 C, USB), micro SD slot for SD™ / SDHC cards up to 32 GB wide range power supply ..................................... 100 Volt to 264 Volt *According to ISO/JIS 388750 MAHR, PS10 Type 388750 PS10  www.precitool.de 38/749
