Microdrill VHM Drilling Tools Design: - special drill bit geometry for low heat generation and highest drilling speeds - cutting edge protection prevents break-outs VHM 30 × D 140° S Cutting data - flute geometry for short chips - flexible centre part - robust unified shank Ø 3 - h5 - special cutting edge geometry for titanium processing 10 Note: Drill pilot hole with 102412 Delivery only in specified PU l4 l2  3-h6 d1 (-0,003 - -0,006) 102460 MIKRON TOOL, CrazyDrill Flex, 30 × D, Titanium d1 l1 l2 l4 d1 l1 l2 l4 d1 l1 l2 l4 Type 102460 Type 102460 Type 102460 mm mm mm mm mm mm mm mm mm mm mm mm 0010  0.10 45 1.1 3.0 1 0047  0.47 50 4.9 14.1 5 0084  0.84 60 8.8 25.2 5 0011  0.11 45 1.2 3.3 5 0048  0.48 50 5.0 14.4 5 0085  0.85 64 8.9 25.5 1 0012  0.12 45 1.3 3.6 5 0049  0.49 50 5.1 14.7 5 0086  0.86 64 9.0 25.8 5 0013  0.13 45 1.4 3.9 5 0050  0.50 53 5.3 15.0 1 0087  0.87 64 9.1 26.1 5 0014  0.14 45 1.5 4.2 5 0051  0.51 53 5.4 15.3 5 0088  0.88 64 9.2 26.4 5 0015  0.15 45 1.6 4.5 1 0052  0.52 53 5.5 15.6 5 0089  0.89 64 9.3 26.7 5 0016  0.16 45 1.7 4.8 5 0053  0.53 53 5.6 15.9 5 0090  0.90 64 9.5 27.0 1 0017  0.17 45 1.8 5.1 5 0054  0.54 53 5.7 16.2 5 0091  0.91 64 9.6 27.3 5 0018  0.18 45 1.9 5.4 5 0055  0.55 53 5.8 16.5 1 0092  0.92 64 9.7 27.6 5 0019  0.19 45 2.0 5.7 5 0056  0.56 53 5.9 16.8 5 0093  0.93 64 9.8 27.9 5 0020  0.20 45 2.1 6.0 1 0057  0.57 53 6.0 17.1 5 0094  0.94 64 9.9 28.2 5 0021  0.21 45 2.2 6.3 5 0058  0.58 53 6.1 17.4 5 0095  0.95 64 10.0 28.5 1 0022  0.22 45 2.3 6.6 5 0059  0.59 53 6.2 17.7 5 0096  0.96 64 10.1 28.8 5 0023  0.23 45 2.4 6.9 5 0060  0.60 53 6.3 18.0 1 0097  0.97 64 10.2 29.1 5 0024  0.24 45 2.5 7.2 5 0061  0.61 53 6.4 18.3 5 0098  0.98 64 10.3 29.4 5 0025  0.25 45 2.6 7.5 1 0062  0.62 53 6.5 18.6 5 0099  0.99 64 10.4 29.7 5 0026  0.26 45 2.7 7.8 5 0063  0.63 53 6.6 18.9 5 0100  1.00 70 10.5 30.0 1 0027  0.27 45 2.8 8.1 5 0064  0.64 53 6.7 19.2 5 0101  1.01 70 10.6 30.3 5 0028  0.28 45 2.9 8.4 5 0065  0.65 53 6.8 19.5 1 0102  1.02 70 10.7 30.6 5 0029  0.29 45 3.0 8.7 5 0066  0.66 53 6.9 19.8 5 0103  1.03 70 10.8 30.9 5 0030  0.30 50 3.2 9.0 1 0067  0.67 53 7.0 20.1 5 0104  1.04 70 10.9 31.2 5 0031  0.31 50 3.3 9.3 5 0068  0.68 53 7.1 20.4 5 0105  1.05 70 11.0 31.5 1 0032  0.32 50 3.4 9.6 5 0069  0.69 53 7.2 20.7 5 0106  1.06 70 11.1 31.8 5 0033  0.33 50 3.5 9.9 5 0070  0.70 60 7.4 21.0 1 0107  1.07 70 11.2 32.1 5 0034  0.34 50 3.6 10.2 5 0071  0.71 60 7.5 21.3 5 0108  1.08 70 11.3 32.4 5 0035  0.35 50 3.7 10.5 1 0072  0.72 60 7.6 21.6 5 0109  1.09 70 11.4 32.7 5 0036  0.36 50 3.8 10.8 5 0073  0.73 60 7.7 21.9 5 0110  1.10 70 11.6 33.0 1 0037  0.37 50 3.9 11.1 5 0074  0.74 60 7.8 22.2 5 0111  1.11 70 11.7 33.3 5 0038  0.38 50 4.0 11.4 5 0075  0.75 60 7.9 22.5 1 0112  1.12 70 11.8 33.6 5 0039  0.39 50 4.1 11.7 5 0076  0.76 60 8.0 22.8 5 0113  1.13 70 11.9 33.9 5 0040  0.40 50 4.2 12.0 1 0077  0.77 60 8.1 23.1 5 0114  1.14 70 12.0 34.2 5 0041  0.41 50 4.3 12.3 5 0078  0.78 60 8.2 23.4 5 0115  1.15 70 12.1 34.5 1 0042  0.42 50 4.4 12.6 5 0079  0.79 60 8.3 23.7 5 0116  1.16 70 12.2 34.8 5 0043  0.43 50 4.5 12.9 5 0080  0.80 60 8.4 24.0 1 0117  1.17 70 12.3 35.1 5 0044  0.44 50 4.6 13.2 5 0081  0.81 60 8.5 24.3 5 0118  1.18 70 12.4 35.4 5 0045  0.45 50 4.7 13.5 1 0082  0.82 60 8.6 24.6 5 0119  1.19 70 12.5 35.7 5 0046  0.46 50 4.8 13.8 5 0083  0.83 60 8.7 24.9 5 0120  1.20 70 12.6 36.0 1 10/66 www.precitool.de
