Micrometers Precision digital external micrometer Design:- for measuring triple-edge tools, e.g. milling cutters or reamers- resolution 0.001 mm DIN863/1ABS Digimatic USB DeliveredU-WAVE®in case - thimble and barrel scale matt chrome-plated, Ø 18 mm - measuring faces with prism angle 60° - frame varnished - measuring spindle with Ø 6.35 mm, pitch 0.75 mm, with clamping mechanism - measuring force 5 - 10 N Functions: - Zero/ABS - Auto Power OFF - Hold - 2× PRESET - low voltage alert - key lock function Delivery: Incl. setting standard and battery. Note: Fitting connection cable see under 398005 on page 39/779. 310591 MITUTOYO 314, with V-anvil, for triple-edged tools Measuring rangemm 310591 Error limitmm Design 1-15  0.008 with grooves 10-25  0.008 with grooves 25-40  0.010 — Precision outside micrometer Design:- for measuring 5-edged tools, like taps or milling cutters- resolution 0.01 mm DIN Delivered863/1in case 31 - thimble and barrel scale matt chrome-plated, Ø 18 mm - measuring faces with prism angle 60° - frame varnished - measuring spindle with Ø 6.35 mm, pitch 0.75 mm, with clamping mechanism - measuring force 5 - 10 N Delivery: Incl. setting standard and setting key. 310593 MITUTOYO 114, for 5-edged tools Measuring rangemm 310593 Error limitmm Design 5-25  0.008 with grooves 25-45  0.010 — 45-65  0.012 — Stand for outside micrometers Design: - solid, steady cast base - pivotable jaws with rubber lining to protect the micrometer - hammertone varnished - both clamping jaw and hinge are fixed in place with one screw 310655 PRECITOOL Type 310655 0100  Setting reference standard Design: - for precision external micrometers 43A 310720 Setting standard for outside micrometers - round steel bars with heat insulated handles - measuring faces = Ø 6.5 mm Setting length- for testing the basic setting of an outside micrometermm310720 - insulating hand sleeves- manufacturing tolerance js2- larger sizes on request 25 5075 100  125  150  175  www.precitool.de 31/667
