Clamping Devices L4 B1 B4 Lo4 Lo3 H5 H1B3 H2 Clamping devices and accessories Design: - for direct mounting of the push-pull type toggle clamp to the fixture - high stability thanks to great material thickness - steel, galvanised and passivated Sizes 0, 3 and 5 Sizes 1 and 2 299600 299601 299600 AMF, angular base for push-pull toggle clamps 299550 and 299580 299601 PRECITOOL, angle base for push-pull type toggle clamp 299581 29 Size0 299600 299601 amm fmm imm bmm cmm—303023 9.016d e g h k l mmmmmmmmmmmmmmm4.5—181310.2315.5-20.5 1  — 60 40 40 11.0 11-18 6.7 22 40 24 12.2 4 40 2   60 40 40 11.0 11-18 6.7 22 40 24 16.2 5 40 3   65 44 50 14.5 19 6.7 — 41 33 20.2 6 41 5  — 70 60 60 17.0 32 9.0 — 45 37 24.0 8 45 Clamping devices and accessories Design and use: - push-pull type toggle clamp - heavy-duty version with long rod guide - body of varnished malleable iron - lever parts and push-rod made of Q & T steel - handle galvanised and with red, oil-resistant plastic handle - rivets made of stainless steel - pre-lubricated bearings - with tempered and galvanised clamping screw and protective cap 299700 Push-pull toggle clamp, heavy-duty version Size 3 5 7 299700    Clamping height Stroke  mm 32 40 50 Clamping power F1  N 4,000 10,000 25,000 Clamping power F2  N 4,000 10,000 25,000 Total height H1  mm 116.0 137.5 179.0 Total length L1  mm 139 174 218 Clamping screw M8 × 35 M12 × 50 M12 × 50 Clamping devices and accessories Design: - actuation of the lever is converted into axial movement of the push rod - automatic, continuous adjustment of the travel at constant clamping force - adjustable clamping force up to 2500 N, depending on the setting of the L3 L5 adjusting screw in the joint L1 - stable, quenched and tempered metal sheets Lo 2Lo 1 - hole pattern of the base plate suited for mm and inch - high-quality 2-component plastic handle L5 L7 L6 L8 299650 Push-pull type toggle clamp with automatic adjustment Clamping rangemm 299650 Clamping powerN Weightkg 25  2,500 0.42 29/620 www.precitool.de
