ACluafsmppainngtiTsacblhes/ MMaaggnent.spPlaantneplsatten Permanent magnet Design: - with radial pole pitch - clamping power continuously adjustable - concentric grooves facilitate workpiece centring - on request an end-to-end centre bore is available to mount centring devices or coolant supply - holding power max. 140 N/cm² - height of magnetic field approx. 12 mm - abrasability pole plate 5 mm - if applied pairwise, please specify when ordering Use: - for turning and grinding - to clamp annular workpieces, like bearings, bushings, spacer rings, etc. - balanced construction suited for high speed, especially designed for hard turning 288401 Chuck for turning and grinding Amm 288401 B C D E F GmmmmmmmmmmmmTapped holes in E and G max. speed Weightmin-1kg 130  57  50 20 — 5 100 4 × M6 × 12 2,500  6 28 150200  57  50 24  80 5 12057 603011051804 × M6 × 124 × M6 × 12 2,500  82,00013 250  70  80 50 140 5 220 4 × M6 × 12 1,500 24 300 + 73 150 58 180 6 260 4 × M8 × 16 1,200 36 Plate demagnetiser Design: - parted pole plate, laminated, made of silicon sheet metal - a pilot lamp signals operating status - voltage 230 V/50 Hz Use: For demagnetising of workpieces with residual magnetism Size 200 × 170 has no parted pole plate 220 × 200 - 500 × 200 200 × 170 288450 made of silicone sheet steel Pole face L × Wmm 288450 Output Length Width Height Weight approx.VAmmmmmmkg 200×170 + 150 200 170 70 3 220×200 + 220 220 200 125 20 350×200 + 440 375 200 125 32 500×200 + 700 525 200 125 46 Sinus table easily swivelling Design: - swivelling around the long axis - all-steel construction with magnetic clamping plate - base body and contact surface 55-62 HRC hardened - swivelling through clamping mechanism mounted underneath the magnetic plate - angular accuracy ± 5 sec. - plane-parallelism ± 0.005/100 mm - max. holding force 70 N/cm² - height of magnetic field approx. 8 mm - abrasability pole plate 5 mm - pole pitch 1.8 mm Use: - for grinding, eroding or measuring - for machining and measuring of precision parts in angular position Note: Angles are determined after the sinus principle by use of the final dimensions up to 45° Sinus chart included in delivery 288460 with magnetic clamping plate A×Bmm 288460 C Weight approx.mmkg 175×100  117 10 255×130  117 20 300×150  117 27 350×150 + 122 35 400×200 + 125 52 28/594 www.precitool.de
