Microdrill VHM Drilling Tools Design: Like 102437 and 102439 VHM coated 30 × D 140° ICS UNI Note: Set pilot hole with 102401, 102403 or 102416, resp. Delivery only in specified PU. Cutting data 10 Example 40 × d d1 (k6) d2 (h6) 102441 MIKRON TOOL, CrazyDrill Cool-XL, 30 × D, eXedur SL, with IC d1 l1 l2 d2 d1 l1 l2 d2 d1 l1 l2 d2 Type 102441 Type 102441 Type 102441 mm mm mm mm mm mm mm mm mm mm mm mm 0100  1.00 73 33.0 4 1 0270  2.70 128 89.1 4 1 0440  4.40 188 145.2 6 1 0110  1.10 76 36.3 4 1 0280  2.80 131 92.4 4 1 0450  4.50 191 148.5 6 1 0120  1.20 80 39.6 4 1 0290  2.90 134 95.7 4 1 0460  4.60 195 151.8 6 1 0130  1.30 83 42.9 4 1 0300  3.00 137 99.0 4 1 0470  4.70 198 155.1 6 1 0140  1.40 86 46.2 4 1 0310  3.10 146 102.3 6 1 0480  4.80 201 158.4 6 1 0150  1.50 89 49.5 4 1 0320  3.20 150 105.6 6 1 0490  4.90 204 161.7 6 1 0160  1.60 92 52.8 4 1 0330  3.30 153 108.9 6 1 0500  5.00 208 165.0 6 1 0170  1.70 96 56.1 4 1 0340  3.40 156 112.2 6 1 0510  5.10 211 168.3 6 1 0180  1.80 99 59.4 4 1 0350  3.50 159 115.5 6 1 0520  5.20 214 171.6 6 1 0190  1.90 102 62.7 4 1 0360  3.60 162 118.8 6 1 0530  5.30 217 174.9 6 1 0200  2.00 105 66.0 4 1 0370  3.70 166 122.1 6 1 0540  5.40 220 178.2 6 1 0210  2.10 109 69.3 4 1 0380  3.80 169 125.4 6 1 0550  5.50 224 181.5 6 1 0220  2.20 112 72.6 4 1 0390  3.90 172 128.7 6 1 0560  5.60 227 184.8 6 1 0230  2.30 115 75.9 4 1 0400  4.00 175 132.0 6 1 0570  5.70 230 188.1 6 1 0240  2.40 118 79.2 4 1 0410  4.10 179 135.3 6 1 0580  5.80 233 191.4 6 1 0250  2.50 121 82.5 4 1 0420  4.20 182 138.6 6 1 0590  5.90 236 194.7 6 1 0260  2.60 125 85.8 4 1 0430  4.30 185 141.9 6 1 0600  6.00 240 198.0 6 1 Note: Set pilot hole with 102401, 102403 or 102416, resp. VHM 40 × D 140° ICS UNI Cutting data Example 40 × d d1 (k6) d2 (h6) 102443 MIKRON TOOL, CrazyDrill Cool-XL, 40 × D, eXedur SL, with IC d1 l1 l2 d2 d1 l1 l2 d2 d1 l1 l2 d2 Type 102443 Type 102443 Type 102443 mm mm mm mm mm mm mm mm mm mm mm mm 0200  2.00 125 86.0 4 1 0340  3.40 190 146.2 6 1 0480  4.80 249 206.4 6 1 0210  2.10 130 90.3 4 1 0350  3.50 194 150.5 6 1 0490  4.90 253 210.7 6 1 0220  2.20 134 94.6 4 1 0360  3.60 198 154.8 6 1 0500  5.00 258 215.0 6 1 0230  2.30 138 98.9 4 1 0370  3.70 203 159.1 6 1 0510  5.10 262 219.3 6 1 0240  2.40 142 103.2 4 1 0380  3.80 207 163.4 6 1 0520  5.20 266 223.6 6 1 0250  2.50 146 107.5 4 1 0390  3.90 211 167.7 6 1 0530  5.30 270 227.9 6 1 0260  2.60 151 111.8 4 1 0400  4.00 215 172.0 6 1 0540  5.40 274 232.2 6 1 0270  2.70 155 116.1 4 1 0410  4.10 220 176.3 6 1 0550  5.50 279 236.5 6 1 0280  2.80 159 120.4 4 1 0420  4.20 224 180.6 6 1 0560  5.60 283 240.8 6 1 0290  2.90 163 124.7 4 1 0430  4.30 228 184.9 6 1 0570  5.70 287 245.1 6 1 0300  3.00 167 129.0 4 1 0440  4.40 232 189.2 6 1 0580  5.80 291 249.4 6 1 0310  3.10 177 133.3 6 1 0450  4.50 236 193.5 6 1 0590  5.90 295 253.7 6 1 0320  3.20 182 137.6 6 1 0460  4.60 241 197.8 6 1 0600  6.00 300 258.0 6 1 0330  3.30 186 141.9 6 1 0470  4.70 245 202.1 6 1 — — — — — — — www.precitool.de 10/53
