Steep Tapers Accessories for steep taper adapters € Design: Pull studs are an important connector between machine and tool. The require- ments concerning accuracy, rigidity and reliability are very high. Pull studs of minor quality not only decrease the performance of the machine, they are even a safety risk. A breaking pull stud might cause severe damage on machine and workpiece and even injuries on persons. Edge protection ring - made of special steel with high rigidity - elaborate heat treatment in several steps - spots with highest stress tempered specifically - high impact strength - all functional surfaces fine finished after hardening - highest security and reliability 247001 KOCH, pull stud, with radial groove and through hole 247005 KOCH, pull stud, with radial groove and internal thread 247006 HAIMER, pull stud with ring groove and internal thread ST 247001 247005 247006 d 1mm d d l l²41 2mmmmmmmm l 3mm d 5 Nm AFmm 40 50   25.0 21.139.332.0 1725 5365 2525 13.60 M16 10013.35M24200 2230 24 Design: Pull studs are an important connector between machine and tool. The require- ments concerning accuracy, rigidity and reliability are very high. Pull studs of minor quality not only decrease the performance of the machine, they are even a safety risk. A breaking pull stud might cause severe damage on machine and workpiece and even injuries on persons - made of special steel with high rigidity - elaborate heat treatment in several steps - spots with highest stress tempered specifically - high impact strength - all functional surfaces fine finished after hardening - highest security and reliability 247020 KOCH, pull stud with saw thread 247021 HAIMER, pull stud with buttress thread ST 247020 247021 d 1mm d4 l1 l2 l3mmmmmmmm d 5 40   S20 × 2 17 53 25 21 M16 Accessories for pull studs ISO 247030 Safety socket wrench ST 7388-1 Type 247030 Mount 0040  ST 40 0050  ST 50 ISO 247032 Safety socket wrench MAS BT 7388-3 Type 247032 Mount 0040  BT 40 0050  BT 50 Accessories for hollow taper adapter Design: - prevents contamination of the spindle - necessary for all HST machines with internal cooling - two O-rings for better flexibility of the tube - special coating with extreme smooth surface, protects the sealing systems of spindles of all makes 242283 HAIMER, coolant transfer pipe HST 242283 G d3 l1 l2mmmmmm 32  M10 × 1.0 6 26.0 5 40  M12 × 1.0 8 29.3 7 50  M16 × 1.0 10 33.0 9 63  M18 × 1.0 12 36.6 11 80  M20 × 1.5 14 40.0 13 100  M24 × 1.5 16 44.0 15 www.precitool.de 24/533
