Microdrill VHM Drilling Tools Design: - solid carbide with straight shank - point angle 140° VHM coated 4×D 140° Straight shank P - eXedur RIP coated - highest drilling speed and durability - self-centring Cutting data - for exceptional surface quality 10 Note: Place a pilot hole using 102401 or 102403, resp. d1 (k5) d2 (h6) 102421 MIKRON TOOL, CrazyDrill Steel, 4 × D, eXedur RIP d1 l1 l2 d2 d1 l1 l2 d2 d1 l1 l2 d2 Type 102421 Type 102421 Type 102421 mm mm mm mm mm mm mm mm mm mm mm mm 0040  0.40 42.0 2.3 3.0 1 0195  1.95 48.0 11.4 3.0 1 0350  3.50 60.0 20.5 4.0 1 0045  0.45 42.0 2.6 3.0 1 0200  2.00 55.0 11.9 4.0 1 0355  3.55 60.0 20.8 4.0 1 0050  0.50 42.0 2.9 3.0 1 0205  2.05 55.0 12.1 4.0 1 0360  3.60 64.5 21.1 4.0 1 0055  0.55 42.0 3.2 3.0 1 0210  2.10 55.0 12.3 4.0 1 0365  3.65 64.5 21.4 4.0 1 0060  0.60 43.5 3.5 3.0 1 0215  2.15 55.0 12.6 4.0 1 0370  3.70 64.5 21.6 4.0 1 0065  0.65 43.5 3.8 3.0 1 0220  2.20 56.0 13.0 4.0 1 0375  3.75 64.5 21.9 4.0 1 0070  0.70 43.5 4.1 3.0 1 0225  2.25 56.0 13.3 4.0 1 0380  3.80 64.5 22.2 4.0 1 0075  0.75 43.5 4.4 3.0 1 0230  2.30 56.0 13.6 4.0 1 0385  3.85 64.5 22.5 4.0 1 0080  0.80 43.5 4.6 3.0 1 0235  2.35 56.0 13.9 4.0 1 0390  3.90 64.5 22.8 4.0 1 0085  0.85 43.5 4.9 3.0 1 0240  2.40 57.0 14.2 4.0 1 0395  3.95 64.5 23.1 4.0 1 0090  0.90 43.5 5.2 3.0 1 0245  2.45 57.0 14.6 4.0 1 0400  4.00 70.0 23.4 6.0 1 0095  0.95 43.5 5.5 3.0 1 0250  2.50 57.0 14.7 4.0 1 0410  4.10 70.0 24.0 6.0 1 0100  1.00 44.0 5.8 3.0 1 0255  2.55 57.0 15.1 4.0 1 0420  4.20 70.0 24.6 6.0 1 0105  1.05 44.0 6.1 3.0 1 0260  2.60 58.0 15.5 4.0 1 0430  4.30 70.0 25.2 6.0 1 0110  1.10 44.0 6.3 3.0 1 0265  2.65 58.0 15.7 4.0 1 0440  4.40 70.0 25.7 6.0 1 0115  1.15 44.0 6.6 3.0 1 0270  2.70 58.0 16.0 4.0 1 0450  4.50 70.0 26.3 6.0 1 0120  1.20 45.0 7.0 3.0 1 0275  2.75 58.0 16.3 4.0 1 0460  4.60 70.0 26.9 6.0 1 0125  1.25 45.0 7.3 3.0 1 0280  2.80 59.0 16.8 4.0 1 0470  4.70 70.0 27.5 6.0 1 0130  1.30 45.0 7.6 3.0 1 0285  2.85 59.0 17.0 4.0 1 0480  4.80 70.0 28.1 6.0 1 0135  1.35 45.0 7.9 3.0 1 0290  2.90 59.0 17.2 4.0 1 0490  4.90 70.0 28.7 6.0 1 0140  1.40 46.0 8.2 3.0 1 0295  2.95 59.0 17.4 4.0 1 0500  5.00 70.0 29.2 6.0 1 0145  1.45 46.0 8.6 3.0 1 0300  3.00 59.0 17.6 4.0 1 0510  5.10 70.0 29.8 6.0 1 0150  1.50 46.0 8.7 3.0 1 0305  3.05 60.0 17.8 4.0 1 0520  5.20 75.0 30.4 6.0 1 0155  1.55 46.0 9.1 3.0 1 0310  3.10 60.0 18.1 4.0 1 0530  5.30 75.0 31.0 6.0 1 0160  1.60 47.0 9.5 3.0 1 0315  3.15 60.0 18.4 4.0 1 0540  5.40 75.0 31.6 6.0 1 0165  1.65 47.0 9.7 3.0 1 0320  3.20 60.0 18.7 4.0 1 0550  5.50 75.0 32.2 6.0 1 0170  1.70 47.0 10.0 3.0 1 0325  3.25 60.0 19.0 4.0 1 0560  5.60 75.0 32.8 6.0 1 0175  1.75 47.0 10.3 3.0 1 0330  3.30 60.0 19.3 4.0 1 0570  5.70 75.0 33.3 6.0 1 0180  1.80 48.0 10.8 3.0 1 0335  3.35 60.0 19.6 4.0 1 0580  5.80 75.0 33.9 6.0 1 0185  1.85 48.0 11.0 3.0 1 0340  3.40 60.0 19.9 4.0 1 0590  5.90 75.0 34.5 6.0 1 0190  1.90 48.0 11.2 3.0 1 0345  3.45 60.0 20.2 4.0 1 0600  6.00 75.0 35.1 6.0 1 Note: Place a pilot hole using 102401 or 102403, resp. 7×D 102423 MIKRON TOOL, CrazyDrill Steel, 7 × D, eXedur RIP d1 l1 l2 d2 d1 l1 l2 d2 d1 l1 l2 d2 Type 102423 Type 102423 Type 102423 mm mm mm mm mm mm mm mm mm mm mm mm 0040  0.40 42.0 3.1 3.0 1 0195  1.95 53.5 17.1 3.0 1 0350  3.50 75.0 31.5 4.0 1 0045  0.45 42.0 3.5 3.0 1 0200  2.00 61.5 18.0 4.0 1 0355  3.55 75.0 32.0 4.0 1 0050  0.50 42.0 3.9 3.0 1 0205  2.05 61.5 18.3 4.0 1 0360  3.60 75.0 32.4 4.0 1 0055  0.55 42.0 4.3 3.0 1 0210  2.10 61.5 18.7 4.0 1 0365  3.65 75.0 32.9 4.0 1 0060  0.60 43.5 4.7 3.0 1 0215  2.15 61.5 19.1 4.0 1 0370  3.70 75.0 33.3 4.0 1 0065  0.65 43.5 5.0 3.0 1 0220  2.20 63.0 20.0 4.0 1 0375  3.75 75.0 33.8 4.0 1 0070  0.70 43.5 5.4 3.0 1 0225  2.25 63.0 20.3 4.0 1 0380  3.80 75.0 34.2 4.0 1 0075  0.75 43.5 5.8 3.0 1 0230  2.30 63.0 20.6 4.0 1 0385  3.85 75.0 34.7 4.0 1 0080  0.80 45.0 6.2 3.0 1 0235  2.35 63.0 20.9 4.0 1 0390  3.90 75.0 35.1 4.0 1 0085  0.85 45.0 6.6 3.0 1 0240  2.40 64.5 21.7 4.0 1 0395  3.95 75.0 35.6 4.0 1 0090  0.90 45.0 7.0 3.0 1 0245  2.45 64.5 22.1 4.0 1 0400  4.00 80.0 36.0 6.0 1 0095  0.95 45.0 7.4 3.0 1 0250  2.50 64.5 22.2 4.0 1 0410  4.10 80.0 36.9 6.0 1 0100  1.00 46.0 7.8 3.0 1 0255  2.55 64.5 22.6 4.0 1 0420  4.20 80.0 37.8 6.0 1 0105  1.05 46.0 8.1 3.0 1 0260  2.60 66.0 23.5 4.0 1 0430  4.30 80.0 38.7 6.0 1 0110  1.10 46.0 8.6 3.0 1 0265  2.65 66.0 23.7 4.0 1 0440  4.40 80.0 39.6 6.0 1 0115  1.15 46.0 8.7 3.0 1 0270  2.70 66.0 24.0 4.0 1 0450  4.50 85.0 40.5 6.0 1 0120  1.20 49.0 10.9 3.0 1 0275  2.75 66.0 24.3 4.0 1 0460  4.60 85.0 41.4 6.0 1 0125  1.25 49.0 11.1 3.0 1 0280  2.80 67.5 25.3 4.0 1 0470  4.70 85.0 42.3 6.0 1 0130  1.30 49.0 11.5 3.0 1 0285  2.85 67.5 25.5 4.0 1 0480  4.80 85.0 43.2 6.0 1 0135  1.35 49.0 11.9 3.0 1 0290  2.90 67.5 25.7 4.0 1 0490  4.90 85.0 44.1 6.0 1 0140  1.40 50.5 12.7 3.0 1 0295  2.95 67.5 25.9 4.0 1 0500  5.00 85.0 45.0 6.0 1 0145  1.45 50.5 12.9 3.0 1 0300  3.00 67.5 26.2 4.0 1 0510  5.10 90.0 45.9 6.0 1 0150  1.50 50.5 13.4 3.0 1 0305  3.05 70.0 27.5 4.0 1 0520  5.20 90.0 46.8 6.0 1 0155  1.55 50.5 13.7 3.0 1 0310  3.10 70.0 27.9 4.0 1 0530  5.30 90.0 47.7 6.0 1 0160  1.60 52.0 14.5 3.0 1 0315  3.15 70.0 28.4 4.0 1 0540  5.40 90.0 48.6 6.0 1 0165  1.65 52.0 14.7 3.0 1 0320  3.20 70.0 28.8 4.0 1 0550  5.50 90.0 49.5 6.0 1 0170  1.70 52.0 15.0 3.0 1 0325  3.25 70.0 29.3 4.0 1 0560  5.60 90.0 50.4 6.0 1 0175  1.75 52.0 15.3 3.0 1 0330  3.30 70.0 29.7 4.0 1 0570  5.70 95.0 51.3 6.0 1 0180  1.80 53.5 16.3 3.0 1 0335  3.35 70.0 30.2 4.0 1 0580  5.80 95.0 52.2 6.0 1 0185  1.85 53.5 16.5 3.0 1 0340  3.40 70.0 30.6 4.0 1 0590  5.90 95.0 53.1 6.0 1 0190  1.90 53.5 16.9 3.0 1 0345  3.45 75.0 31.1 4.0 1 0600  6.00 95.0 54.0 6.0 1 10/48 www.precitool.de
