| Output | approx� 13 kW |
| Connection | 3× 400-480 V, 16 A |
| Tools made of | HM and HSS |
| Tool | 3 - 16 mm |
| Max� length of the shrink-fit | |
| 230 mm | |
| chuck | |
| Width × depth × height | 715 × 600 × 630 mm |
| Weight | 75 kg |
Design: - shrink-fit unit for small tools - easy tool handling due to horizontal shrinking
242671 HAIMER, Power Clamp Nano 24
Type 242671 NANO +
Shrink-fit unit
| Technical Data: | |
| Output | 10 kW |
| Connection | 3× 400-480 V, 16 A |
| Tools made of | HM and HSS |
| Tool | 3-32 mm |
| Max� length of the shrink-fit chuck | 350 mm |
| Width × depth × height | 650 × 900 × 600 mm |
| Weight | 45 kg |
Design: - shrink-fit unit for all tools - coil with 5 stop disks - single-user version - cooling only by use of Air Cooler - incl. 1 basic holder and 1 receptacle
242702 HAIMER, Power Clamp Basic without cooling
Type 242702 0001 +
Shrink-fit unit
Technical Data:
| Output | 13 kW |
| Connection | 3× 400-480 V, 16 A |
| Tools made of | HM and HSS |
| Tool | 3-32 mm |
| Max� length of the shrink-fit | |
| 570 mm | |
| chuck | |
| Width × depth × height | 860 × 600 × 970 mm |
| Weight | 70 kg |
Design: - for all tools - high-performance shrink-fit unit single-user version - with integrated contact cooling
- incl. Cool Manager - incl. 1 basic holder and 1 receptacle - incl. new NG coil technology
