| - for the production of special tools | DIN | Form | |
| - HST cone and collar ground and hardened | 69893 | A/C | A |
- cylindrical section soft for further processing
242309 PRECITOOL, blank
| HST × d1 mm × l1 mm | 242309 | |
| 63×63×160 | | |
| 63×63×250 | | |
| 63×80×250 | | |
| 100×63×200 | | |
| 100×80×250 | | |
| 100×97×315 | | |
| 24 | Hollow taper adapter DIN 69893 A | |
| Delivery: | ISO | |
| With wooden stand and test certificate | Form DIN |
12164 69893 A A/C
242281 PRECITOOL, test mandrel
HST/d l
| 1 242281 | 1 | |
| mm | mm | |
| 63/40 | | 300 |
| 100/50 | | 300 |
| Hollow taper adapter DIN 69893 E | ||
| Design: | ISO |
| - for highest cutting performance at HSS operations | DIN | Form | |
| 69893 | 12164 | E |
- high rigidity with vibration damping A/C - high concentricity of 0.003 mm at 3 × D with Haimer Power Collets - also for standard collets ER to ISO 15488 (Attention: When used with standard collets the I dimension is longer)
- higher running smoothness thanks to vibration absorbing geometry, 1 therefore better surface quality - increased chipping capacity due to higher speed, greater feed and greater cutting depth - shorter machining times - better dimensional stability - high clamping power - ideally suited for HSS and heavy-duty machining - with threaded holes for balancing screws
Note: - matching collets see under 248910, 248920 and 248930 on page 24/514 l 2 - fitting tightening bolts see under 246542 on page 24/498 l 1
242900 HAIMER, collet chuck HP, ultra short
| HST/collet chuck | 242900 | d | d | l | l | HST/collet chuck | 242900 | d | d | l | l |
| mm1 | mm3 | mm1 | mm2 | mm1 | mm3 | mm1 | mm2 | ||||
| 32/ER16 | | 2�0 - 10 | 28 | 50 | 32�0 | 40/ER32 | | 2�0 - 20 | 50 | 70 | 47�0 |
| 32/ER25 | | 2�0 - 16 | 42 | 60 | 39�0 | 50/ER16 | | 2�0 - 10 | 28 | 60 | 32�0 |
| 40/ER16 | | 2�0 - 10 | 28 | 50 | 31�0 | 50/ER25 | | 2�0 - 16 | 42 | 65 | 39�0 |
| 40/ER25 | | 2�0 - 16 | 42 | 60 | 38�5 | 50/ER32 | | 2�0 - 20 | 50 | 75 | 48�0 |
242902 HAIMER, collet chuck HP, short
| d | d | l | l | d | d | l | l | ||||||||
| HST/collet chuck | 242902 | 1 | 3 | 1 | 2 | HST/collet chuck | 242902 | 1 | 3 | 1 | 2 | ||||
| 40/ER16 | | 2�0 - 10 | 28 | 80 | 43�0 | 40/ER32 | | 2�0 - 20 | 50 | 80 | 53�0 | ||||
| 40/ER25 | | 2�0 - 16 | 42 | 80 | 51�0 | — | — | — | — | — | — |
