Steep Tapers Hollow taper adapter DIN 69893 A Design:- short, heavy-duty version, with axial length adjustment- for automatic tool change DIN69893 ISO12164A/CFormA HPC HSC G 2,5 25.000 min-1 - with vibration damping and radial rigidity - concentricity < 0.003 mm - maximum speed 50,000 rpm-1 - clamping without peripherals, only with an Allen key Note: Intermediate sleeve see 241461 and 241462 on page 24/527. 24 241420 SCHUNK, hydraulic expansion chuck Tendo E compact, short, heavy-duty HST/D1mm 241420 D 2mm D X L L L L41²3 5mmmmmmmmmmmmL 6mm L 7mm G M mminNmkg 63/12  42.0 32 34 80 46 10 4.5 31.0 54 M8 × 1 — — 63/16  52.5 38 29 80 51 10 5.0 37.0 54 M8 × 1 350 1.3 63/20  51.5 33 29 80 51 10 5.0 36.5 54 M8 × 1 360 1.3 Hollow taper adapter DIN 69893 A Design:- long, slim version with axial length adjustment- for automatic tool change DIN69893 ISO12164A/CFormA HPC HSC G 2,5 25.000 min-1 - with vibration damping - concentricity < 0.003 mm - maximum speed 50,000 rpm-1 - clamping without peripherals, only with an Allen key Note: Intermediate sleeve see 241461 and 241462 on page 24/527. 241426 SCHUNK, hydraulic expansion chuck Tendo, long, slim HST/D1mm 241426 D2 D3mmmm D4mm Xmm L1mm L²mm L3mm L4mm L5mm L6mm L7mm G Mmin mNmkg 63/06  26 50 22 113 150 37 10 103 3.6 20.5 124 M5 16 1.4 63/08  28 50 24 113 150 37 10 104 3.6 20.5 124 M6 23 1.4 63/10  30 50 26 109 150 41 10 104 3.6 25.5 124 M8 × 1 45 1.5 63/12  32 50 28 104 150 46 10 105 3.6 30.5 124 M10 × 1 90 1.5 63/14  34 50 30 104 150 46 10 105 3.6 30.5 124 M10 × 1 110 1.6 63/16  38 50 34 101 150 49 10 106 3.6 35.0 124 M12 × 1 185 1.8 63/18  40 50 36 101 150 49 10 107 3.6 35.0 124 M12 × 1 240 1.8 63/20  42 50 38  99 150 51 10 108 3.7 37.8 124 M16 × 1 330 1.9 www.precitool.de 24/473
