Drill bit grinder
| Technical data: | |
| Connected value | 230 V / 1 Ph ~ 50 Hz |
| Motor power | 80 W |
| Idling speed | 4,200 min-1 |
| Angle of tip sharpening | 118° |
| Grinding capacity drill | x3 - 13 mm |
| Length × width × height | 220 × 200 × 160 mm |
| Weight | 2�50 kg |
Weight 2�50 kg 10
Design: - for occasional sharpening of twist drills X 3 mm to 13 mm X - for cost-effective grinding of double-edged twist drills - drill grinding without prior experience - clean, fast and well
- robust plastic housing with non-slip feet - diamond grindstone with long service life for perfect finish- diamond grindstone with a long life for a perfect finish - easy handling
Delivery: Incl. diamond grinding wheel and collet holder
795005 GQ-D13
| Type | 795005 | Design |
| 0010 | | Drill bit grinder |
| 0015 | | Replacement grinding disk diamond |
Drill bit grinder
| Technical data: | |
| Connected value | 230 V / 1 Ph ~ 50 Hz |
| Motor power | 180 W |
| Idling speed | 5,300 min-1 |
| Angle of tip sharpening | 90° - 135° |
| Grinding capacity drill | x2 - 13 mm |
| Length × width × height | 310 × 180 × 190 mm |
| Weight | 9�50 kg |
Design: - drill grinding machine with simple operation for precise and cost-effective grinding of double-edged twist drills - drill grinding without prior experience - clean, fast and good - diamond grindstone with long service life for a perfect finish - complete equipment with ER collets inside the machine - the cutting edges of the drill are fixed in the collet holder by means of the setting device in a defined position and inserted in a predetermined sequence in the grinding openings in order to grind the cutting edges with a short rotary movement of the collet holder
Delivery: Incl. collets x 2 to 13 mm and collet chuck.
795015 GH 10T
| Type | 795015 | Design | |
| 0010 | | Drill bit grinder | |
| 0015 | | Replacement grind | ing disk diamond |
