- for highest cutting performance at HSS operations	JIS	ISO	Form
- increased chipping capacity due to higher speed, greater feed and greater cutting depth	6339 B	7388-2	AD/B

- shorter machining times - smoother running results in better surface quality and spares tools, spindle and machine - better dimensional stability - with closable Cool Jet holes

- with threaded holes for balancing screws The long versions (l1 = 130-200 mm) with slim tip are especially versatile in use - high rigidity - slim at the tip - vibration-damping - high clamping power - ideally suited for HSS and heavy-duty machining - universally applicable, saves space in the tool magazine - concentricity < 3 µm

Note: - all versions also available with SAFE-LOCK® - matching accessories see page 24/522 et seq.

HPC

HSC G 2,5 25.000 min-1

l 1

10 l 2 24

242830 HAIMER, shrink-fit chuck Power, ultra short

BT/ d1mm	242830	d3 mm	l1 mm	l2 mm	BT/ d1mm	242830	d3 mm	l1 mm	l2 mm
40/06		22�0	70	36	40/16		29�5	75	50
40/08		22�0	70	36	40/18		35�5	75	50
40/10		26�5	70	42	40/20		35�5	75	52
40/12		26�5	70	47	40/25		45�5	85	58
40/14		29�5	75	47	40/32		45�5	85	58

242831 HAIMER, shrink-fit chuck Power, short

BT/ d1mm	242831	d3 mm	l1 mm	l2 mm	BT/ d1mm	242831	d3 mm	l1 mm	l2 mm
50/06		21�0	100	36	50/16		33�3	100	50
50/08		21�0	100	36	50/18		44�7	100	50
50/10		27�0	100	42	50/20		44�7	100	52
50/12		27�0	100	47	50/25		44�7	100	58
50/14		33�3	100	47	—	—	—	—	—

242835 HAIMER, shrink-fit chuck Power, ZG130

BT/ d1mm	242835	d3 mm	l1 mm	l2 mm	BT/ d1mm	242835	d3 mm	l1 mm	l2 mm
40/06		21	130	36	40/14		27	130	47
40/08		21	130	36	40/16		27	130	50
40/10		24	130	42	40/18		33	130	50
40/12		24	130	47	40/20		33	130	52

242837 HAIMER, shrink-fit chuck Power, overlong

BT/ d1mm	242837	d3 mm	l1 mm	l2 mm	BT/ d1mm	242837	d3 mm	l1 mm	l2 mm
40/06		21	160	36	50/08		21	160	36
40/08		21	160	36	50/10		27	160	42
40/10		24	160	42	50/12		27	160	47
40/12		24	160	47	50/14		33	160	47
40/14		27	160	47	50/16		33	160	50
40/16		27	160	50	50/18		44	160	50
40/18		33	160	50	50/20		44	160	52
40/20		33	160	52	50/25		44	160	58
50/06		21	160	36	—	—	—	—	—

242839 HAIMER, shrink-fit chuck Power, ZG200

BT/ d1mm	242839	d3 mm	l1 mm	l2 mm	BT/ d1mm	242839	d3 mm	l1 mm	l2 mm
50/06		21	200	36	50/16		33	200	50
50/08		21	200	36	50/18		44	200	50
50/10		27	200	42	50/20		44	200	52
50/12		27	200	47	50/25		44	200	58
50/14		33	200	47	—	—	—	—	—
