Steep Tapers Ød1 Ød3 Steep taper adapter JIS B 6339 Use: - for clamping of milling cutters with parallel shank and lateral drive surface toDIN 1835-B and DIN 6535-HB, similar to DIN 6359 with steep taperJIS ISO Form Form DIN6339 B7388-2ADAD/B6359 - JIS B 6339 BT form ADB: - central coolant supply and resealable coolant ducts at collar Delivery: With clamping screw Note: 241003/241004, 241007: d1 ≤ 10 Ø conical l1 24 241002 PRECITOOL, Weldon chuck, form AD, short, G6.3 at 15,000 1/min 241000 PRECITOOL, Weldon chuck, short, form AD/B, G6.3 at 15,000 1/min 241001 HAIMER, Weldon chuck, short, form AD/B, G2.5 at 22,000 1/min BT/d1 mm241000 241001 241002 241000d3 × l1mm 241001 241002d3 × l1mmd3 × l1mmLockingthreadBT/d1 mm241000241001241002241000d3 × l1mm 241001 241002d3 × l1mmd3 × l1mmLockingthread 30/06 — —  — — 25 × 50 M12 40/25      65 ×   90 59 ×   90 65 ×   90 M16 30/08 — —  — — 28 × 50 M12 40/32      72 × 100 72 × 100 72 × 100 M16 30/10 — —  — — 35 × 50 M12 40/40 — —  — — 80 × 105 M16 30/12 — —  — — 42 × 55 M12 50/06      25 ×   63 25 ×   63 25 ×   63 M24 30/14 — —  — — 44 × 63 M12 50/08      28 ×   63 28 ×   63 28 ×   63 M24 30/16 — —  — — 48 × 63 M12 50/10      35 ×   80 35 ×   70 35 ×   70 M24 30/18 — —  — — 50 × 63 M12 50/12      42 ×   80 42 ×   80 42 ×   80 M24 30/20 — —  — — 52 × 70 M12 50/14  —    44 ×   80 — 44 ×   80 M24 40/06    25 × 50 25 × 50 25 × 50 M16 50/16      48 ×   80 48 ×   80 48 ×   80 M24 40/08    28 × 50 28 × 50 28 × 50 M16 50/18  —    50 ×   80 — 50 ×   80 M24 40/10    35 × 63 35 × 63 35 × 63 M16 50/20      52 ×   80 52 ×   80 52 ×   80 M24 40/12    42 × 63 42 × 63 42 × 63 M16 50/25      65 × 100 65 × 100 65 × 100 M24 40/14    44 × 63 44 × 63 44 × 63 M16 50/32      72 × 105 72 × 105 72 × 105 M24 40/16    48 × 63 48 × 63 48 × 63 M16 50/40      80 × 120 78 × 115 80 × 120 M24 40/18    50 × 63 50 × 63 50 × 63 M16 50/50  — — 100 × 125 — — M24 40/20    52 × 63 52 × 63 52 × 63 M16 — — — — — — — — 241003 PRECITOOL, Weldon chuck, form AD, long, G6.3 at 15,000 1/min 241004 PRECITOOL, Weldon chuck, form AD/B, long, G6.3 at 15,000 1/min 241005 HAIMER, Weldon chuck, form AD/B, long, G2.5 at 22,000 1/min BT/d1 mm241003 241004 241005 241003d3 × l1mm 241004d3 × l1mm 241005d3 × l1mmLockingthreadBT/d1 mm241003 241004 241005 241003d3 × l1mm 241004d3 × l1mm 241005d3 × l1mmLockingthread 40/06    25 × 100 25 × 100 25 × 100 M16 50/06 —  — — 25 × 100 — M24 40/08    28 × 100 28 × 100 28 × 100 M16 50/08 —  — — 28 × 100 — M24 40/10    35 × 100 35 × 100 35 × 100 M16 50/10 —   — 35 × 100 35 × 100 M24 40/12    42 × 100 42 × 100 42 × 100 M16 50/12 —   — 42 × 100 42 × 100 M24 40/14   — 44 × 100 44 × 100 — M16 50/14 —  — — 44 × 100 — M24 40/16    48 × 100 48 × 100 48 × 100 M16 50/16 —   — 48 × 100 48 × 100 M24 40/18   — 50 × 100 50 × 100 — M16 50/18 —  — — 50 × 100 — M24 40/20    52 × 100 52 × 100 52 × 100 M16 50/20 —   — 52 × 100 52 × 100 M24 241007 HAIMER, Weldon chuck, form AD/B, overlong, G2.5 at 15,000 1/min 241008 HAIMER, Weldon chuck, form AD/B, overlong, G2.5 at 22,000 1/min BT/d1 mm 241007 241008 241007d ×l3 1mm 241008d ×l3 1mm Lockingthread BT/d1 mm 241007 241008 241007d ×l3 1mm 241008d ×l3 1mm Lockingthread 40/06   25 × 160 25 × 160 M16 50/08   28 × 160 28 × 160 M24 40/08   28 × 160 28 × 160 M16 50/10   35 × 160 35 × 160 M24 40/10   35 × 160 35 × 160 M16 50/12   42 × 160 42 × 160 M24 40/12   42 × 160 42 × 160 M16 50/14  — 44 × 160 — M24 40/14  — 44 × 160 — M16 50/16   48 × 160 48 × 160 M24 40/16   48 × 160 48 × 160 M16 50/18  — 50 × 160 — M24 40/18  — 50 × 160 — M16 50/20   52 × 160 52 × 160 M24 40/20   52 × 160 52 × 160 M16 50/25   65 × 160 65 × 160 M24 40/25   65 × 160 59 × 160 M16 50/32   72 × 160 72 × 160 M24 40/32   72 × 160 72 × 160 M16 50/40  — 80 × 160 — M24 50/06   25 × 160 25 × 160 M24 — — — — — — 24/438 www.precitool.de
