Steep ta	per adapter DIN 69	871
Design: - basic setting for - concentricity 0.0	m AD 05 mm Not Matc	e: hing accessori	DIN 69871 ISO 7388-1 Form AD HPC HSC es see page 24/530
- maximum speed - internal coolant s -241600 4020:W	20,000 rpm-1 upply possible, air outlet holes a ithout undercut to DIN 69871 in	re to be closed front of the gri	2 with 2 screws M4 × 5 pper collar
241600 NT, h	igh-performance powe	r chuck, ty	pe CTS, extra short
ST/d1	241600	d3	l1 l2
mm		mm	mm mm
40/20		52	75 56
241602 NT, h	igh-performance powe	r chuck, ty	1 pe CTS, short
ST/d1 mm	241602	d3 mm	l1 mm l2 mm
40/16		45	90 65
40/20		52	90 80
50/16		45	90 65
50/20		52	90 80
50/32		73	95 120
241604 NT, h	igh-performance powe	r chuck, ty	pe CTS, long
ST/d1 mm	241604 d3 mm	l1 mm	l2 mm
40/20	 52	105	80 241606 NT, high-performance power chuck, type CTS,
40/25	 61	105	80 extra long
40/32	 73	105	85
50/16	 45	105	65 ST/d1 241606 d3 l1 l2
50/20	 52	105	80 mm mm mm mm
50/25	 61	105	80 40/20  52 120 80
50/32	 73	105	120 40/32  73 120 85

Steep ta	per ada	pter D	IN 698	71
Use: For mounting scre	w-in milling cu	tters with	thread			l1		DIN	ISO	Form	G 2,5
							6 l2	9871 7	388-1	AD/B	25.000 min-1
Note: Mhi	i
atcng accesso see ae 24/531	es	FORM	AD
pg 241079 PREC	ITOOL, s	FORM crew-in	B chuck,	extra	short	D3 d4	M d1 d3
ST × thread	241079	d1 mm	d3 mm	d4 mm	l1 mm	l2 mm	ST × thread	241079		d1 mm	d3 mm	d4 mm	l1 mm	l2 mm
40×M6		6�5	10	13	44	25	40×M12			12�5	21	24	44	25
40×M8		8�5	13	15	44	25	40×M16			17�0	29	29	44	25
40×M10		10�5	18	20	44	25	—	—		—	—	—	—	—
241080 PREC	ITOOL, s	crew-in d	chuck, d	short d	l	l				d	d	d	l	l
ST × thread	241080	1 mm	3 mm	4 mm	1 mm	2 mm	ST × thread	241080		1 mm	3 mm	4 mm	1 mm	2 mm
40×M6		6�5	10	20	69	50	50×M8			8�5	13	23	69	50
40×M8		8�5	13	23	69	50	50×M10			10�5	18	23	69	50
40×M10		10�5	18	23	69	50	50×M12			12�5	21	24	69	50
40×M12		12�5	21	23	69	50	50×M16			17�0	29	34	69	50
40×M16		17�0	29	34	69	50	—	—		—	—	—	—	—
241081 PREC	ITOOL, s	crew-in	chuck,	long
ST × thread	241081	d1 mm	d3 mm	d4 mm	l1 mm	l2 mm	ST × thread	241081		d1 mm	d3 mm	d4 mm	l1 mm	l2 mm
40×M6		6�5	10	23	94	75	50×M8			8�5	13	25	119	100
40×M8		8�5	13	23	94	75	50×M10			10�5	18	32	119	100
40×M10		10�5	18	28	94	75	50×M12			12�5	21	33	119	100
40×M12		12�5	21	31	94	75	50×M16			17�0	29	36	119	100
40×M16		17�0	29	34	94	75	—	—		—	—	—	—	—
241082 PREC	ITOOL, s	crew-in	chuck,	overlo	ng
ST × thread	241082	d1 mm	d3 mm	d4 mm	l1 mm	l2 mm	ST × thread	241082		d1 mm	d3 mm	d4 mm	l1 mm	l2 mm
40×M8		8�5	13	25�0	119	100	50×M8			8�5	13	30�0	169	150
40×M10		10�5	18	32�0	119	100	50×M10			10�5	18	36�5	169	150
40×M12		12�5	21	32�0	119	100	50×M12			12�5	21	40�0	169	150
40×M16		17�0	29	36�0	119	100	50×M16			17�0	29	43�0	169	150
