Общий каталог PRECITOOL - страница 418

d1 d3 Steep Tapers Steep taper adapter DIN 69871 Use: - for clamping of milling cutters with parallel shank and lateral drive surface DIN ISO Form Form DIN to DIN 1835-B and DIN 6535-HB 69871 7388-1 AD AD/B 6359 - to DIN 6359 with steep taper - form ADB: Central coolant supply and resealable coolant ducts at collar Delivery: With clamping screw Note: - spare clamping screws see under 240570 on page 24/495 - *also suited for ANSI-CAT - 240491/240509, 240492/240511: d1 ≤ 10  tapered l1 24 240491 PRECITOOL, Weldon chuck, form AD, long, G6.3 at 15,000 1/min 240509 PRECITOOL, Weldon chuck, form AD/B, long, G2.5 at 25,000 1/min 240510 HAIMER, Weldon chuck, form AD/B, long, G2.5 at 22,000 1/min ST/d1mm 240491 240509 240510 240491d3 × l1mm240509d3 × l1mm240510d3 × l1mm*LockingthreadST/d1mm240491240509240510 240491d3 × l1mm240509d3 × l1mm240510d3 × l1mm*Lockingthread 40/06    25 × 100 25 × 100 25 × 100 * M16 50/08    28 × 100 28 × 100 28 × 100 * M24 40/08    28 × 100 28 × 100 28 × 100 * M16 50/10    35 × 100 35 × 100 35 × 100 * M24 40/10    35 × 100 35 × 100 35 × 100 * M16 50/12    42 × 100 42 × 100 42 × 100 * M24 40/12    42 × 100 42 × 100 42 × 100 * M16 50/14    44 × 100 44 × 100 42 × 100 * M24 40/14    44 × 100 44 × 100 42 × 100 * M16 50/16    48 × 100 48 × 100 48 × 100 * M24 40/16    48 × 100 48 × 100 48 × 100 M16 50/18    50 × 100 50 × 100 48 × 100 * M24 40/18    50 × 100 50 × 100 48 × 100 M16 50/20    52 × 100 52 × 100 52 × 100 * M24 40/20    52 × 100 52 × 100 52 × 100 M16 50/25    65 × 100 65 × 100 65 × 100 * M24 50/06    25 × 100 25 × 100 25 × 100 * M24 — — — — — — — — — 240515 HAIMER, Weldon chuck, form AD/B, ZG130, G2.5 at 22,000 1/min ST/d1mm 240515 240515d3 × l1mm * Lockingthread ST/d1mm 240515 240515d3 × l1mm * Lockingthread 50/06  25 × 130 * M24 50/18  48 × 130 * M24 50/08  28 × 130 * M24 50/20  52 × 130 * M24 50/10  35 × 130 * M24 50/25  65 × 130 * M24 50/12  42 × 130 * M24 50/32  72 × 130 M24 50/14  42 × 130 * M24 50/40  78 × 130 M24 50/16  48 × 130 * M24 — — — — — 240492 PRECITOOL, Weldon chuck, form AD, overlong, G6.3 at 15,000 1/min 240511 PRECITOOL, Weldon chuck, form AD/B, overlong, G2.5 at 25,000 1/min 240520 HAIMER, Weldon chuck, form AD/B, overlong, G2.5 at 22,000 1/min ST/d1mm 240492 240511 240520 240492d3 × l1mm240511d3 × l1mm240520d3 × l1mm*LockingthreadST/d1mm240492240511240520 240492d3 × l1mm240511d3 × l1mm240520d3 × l1mm*Lockingthread 40/06    25 × 160 25 × 160 25 × 160 * M16 50/08    28 × 160 28 × 160 28 × 160 * M24 40/08    28 × 160 28 × 160 28 × 160 * M16 50/10    35 × 160 35 × 160 35 × 160 * M24 40/10    35 × 160 35 × 160 35 × 160 * M16 50/12    42 × 160 42 × 160 42 × 160 * M24 40/12    42 × 160 42 × 160 42 × 160 * M16 50/14    42 × 160 42 × 160 42 × 160 * M24 40/14    42 × 160 42 × 160 42 × 160 * M16 50/16    48 × 160 48 × 160 48 × 160 * M24 40/16    48 × 160 48 × 160 48 × 160 M16 50/18    48 × 160 48 × 160 48 × 160 * M24 40/18    48 × 160 48 × 160 48 × 160 M16 50/20    52 × 160 52 × 160 52 × 160 * M24 40/20    52 × 160 52 × 160 52 × 160 M16 50/25    65 × 160 65 × 160 65 × 160 M24 40/25    65 × 160 65 × 160 65 × 160 M16 50/32    72 × 160 72 × 160 72 × 160 M24 40/32   — 72 × 160 72 × 160 — M16 50/40    78 × 160 78 × 160 78 × 160 M24 50/06    25 × 160 25 × 160 25 × 160 * M24 — — — — — — — — — 240525 HAIMER, Weldon chuck, form AD/B, ZG200, G2.5 at 22,000 1/min ST/d1mm 240525 240525d3 × l1mm * Lockingthread ST/d1mm 240525 240525d3 × l1mm * Lockingthread 50/06  25 × 200 * M24 50/14  42 × 200 * M24 50/08  28 × 200 * M24 50/16  48 × 200 * M24 50/10  35 × 200 * M24 50/18  48 × 200 * M24 50/12  42 × 200 * M24 50/20  52 × 200 * M24 www.precitool.de 24/413
