Boring bar ISO 12164-3

- for efficient turning	DIN	ISO
- driving grooves at HST to ICTM standard	69893	12164-3

237180 for replaceable head

Type	237180	HST T	D mm	A mm	L1 mm
4025×90		40	25	90	35
4025×110		40	25	110	55
4032×115		40	32	115	60
4040×120		40	40	120	—
6325×105		63	25	105	44
6332×125		63	32	125	64
6332×160		63	32	160	99
6340×140		63	40	140	74
6340×180		63	40	180	114

D

23 DIN ISO

69893 12164-3

237181 for replaceable head, vibration-damped

D HSK T L1 A

Type	237181	HST T	D mm	A mm	L1 mm
6325×150		63	25	150	89
6332×185		63	32	185	124
6340×225		63	40	225	159

Boring bar ISO 26623-1

Design: - for efficient turning ISO - driving grooves at HST to ICTM standard 26623-1

237183 for replaceable head

D

Type	237183	PSC	D mm	A mm	L1 mm
4025×90		40	25	90	35
4032×110		40	32	110	55
4040×120		40	40	120	—
5025×90		50	25	90	35
5032×110		50	32	110	55
5040×140		50	40	140	80
6325×100		63	25	100	43
6332×125		63	32	125	68
6332×160		63	32	160	103
6340×140		63	40	140	78
6340×180		63	40	180	118

PSC

ISO 26623-1 D PSC L1 237184 for replaceable head, vibration-damped A

Type	237184	PSC	D mm	A mm	L1 mm
6325×150		63	25	150	93
6332×185		63	32	185	128
6340×225		63	40	225	163
