Tool Holders D 5mD5mD5m dmtdmtdmt DD1 D21 1 Tool adapter ISO 26623-1 Design: - short- without gripper groove ISO DIN ISO26623-1649915488 lC l3 235801 Collet adapter l21 Type 235801 SizeCoupling D5m min. d mt max. d mt D21mmmmmmmm lCmm l3 l21mmmm Weightkg Nm Collet 0316  C3 32 0.5 10 28 32.5 24 30 0.12 56 ER 16 0320  C3 32 1.0 13 34 38.0 29 35 0.15 80 ER 20 0325  C3 32 1.0 16 42 41.0 — 44 0.25 104 ER 25 0420  C4 40 1.0 13 34 38.0 26 32 0.20 80 ER 20 23 04250432  C4 40 1.0C4402.0 16 42 41.0 29 35 0.25 104 ER 25205047.0—520.43136ER 32 0525  C5 50 1.0 16 42 41.0 28 34 0.35 104 ER 25 0532  C5 50 2.0 20 50 47.0 35 41 0.42 136 ER 32 0540  C5 50 2.0 26 63 53.0 — 58 0.76 176 ER 40 0632  C6 63 2.0 20 50 47.0 34 42 0.64 136 ER 32 0640  C6 63 2.0 26 63 53.0 40 48 0.79 176 ER 40 Design: - only for segment clamping- not for use in basic holders and extensions/reductions lC ISO26623-1 - not suited for automatic tool change (ATC) - short - without gripper groove Delivery: Without setting screw l3 235803 Hydraulic expansion adapter l21 Type 235803 Size D5m d mt D1 lC l3 l21 WeightmmmmmmmmmmmmkgCollet 0312  C3 32 12 43.5 45 36 42 0.4 12 0416  C4 40 16 48.0 48 36 42 0.5 16 0520  C5 50 20 52.0 53 40 46 0.7 20 0625  C6 63 25 59.0 58 44 50 1.1 25 Design: - for shanks to DIN 6535-HB and -HE ISO DIN - only for segment clamping- not for use in basic holders and extensions/reductions 26623-1 6535lC - not suited for automatic tool change (ATC)- short l1 - without gripper groove 0° Delivery: Without setting screw 2° l3 235805 Weldon/Whistle-Notch adapter l21 Type 235805 Size D5m d mt D1 l1 lC l3 l21mmmmmmmmmmmmmmWeight kg Type 235805 Size D5m d mt D1 l1 lC l3 l21 Weightmmmmmmmmmmmmmmkg 0306  C3 32 6 19 15.0 36 27 33 0.12 0512  C5 50 12 34 15.5 45 32 38 0.42 0308  C3 32 8 21 15.0 36 27 33 0.12 0514  C5 50 14 36 15.5 45 32 38 0.44 0310  C3 32 10 28 17.0 40 31 37 0.19 0516  C5 50 16 38 17.0 49 35 41 0.47 0312  C3 32 12 34 19.5 45 — 42 0.28 0518  C5 50 18 40 18.0 49 36 42 0.50 0314  C3 32 14 36 20.5 45 — 43 0.31 0520  C5 50 20 45 19.0 51 38 44 0.58 0316  C3 32 16 38 27.0 49 — 51 0.39 0525  C5 50 25 51 26.0 57 — 50 0.72 0406  C4 40 6 19 12.0 36 24 30 0.17 0606  C6 63  6 19 12.0 36 22 30 0.51 0408  C4 40 8 21 12.0 36 24 30 0.18 0608  C6 63  8 21 13.0 36 23 31 0.52 0410  C4 40 10 28 14.0 40 28 34 0.24 0610  C6 63 10 28 14.0 40 26 34 0.57 0412  C4 40 12 34 16.5 45 33 39 0.32 0612  C6 63 12 34 14.5 45 29 37 0.63 0414  C4 40 14 36 16.5 45 33 39 0.34 0614  C6 63 14 36 14.5 45 29 37 0.64 0416  C4 40 16 38 19.0 49 37 43 0.38 0616  C6 63 16 38 17.0 49 33 41 0.69 0418  C4 40 18 40 19.0 49 — 43 0.40 0618  C6 63 18 40 17.0 49 33 41 0.70 0420  C4 40 20 45 20.0 51 — 45 0.49 0620  C6 63 20 45 18.0 51 35 43 0.77 0506  C5 50 6 19 11.0 36 23 29 0.28 0625  C6 63 25 51 26.0 57 42 50 0.92 0508  C5 50 8 21 11.0 36 23 29 0.29 0632  C6 63 32 72 30.0 61 46 54 1.33 0510  C5 50 10 28 13.0 40 27 33 0.34 — — — — — — — — — — — 23/362 www.precitool.de
