Twist drill set HSS
| 100510: DIN 338 HSS twist drill set, CBN-ground, 100020 in plastic case | DIN | Type | P | |
| 100520: Set of twist drills DIN 338, roll-forged, 100010 in metal case | 338 | N | Straight |
118° shank 100525: Set of twist drills DIN 338, profile ground, 100015 in plastic case *Sizes 1.0 - 10.5 with core hole dimensions 1x each 3.3/4.2/6.8/10.2 mm 10
100510 100532
100520
100510 PRECITOOL, set, CBN ground
100520 PRECITOOL, set HSS, roll-forged
100525 PRECITOOL, set HSS, profile ground
100532 PRECITOOL, plastic case, empty
100533 PRECITOOL, plastic stand, empty (without fig.)
| Xarea mm | 100510 | 100520 | 100525 | 100532 | 100533 | Quantity of drills | increment each about mm |
| 1,0-5,0 | — | — | — | — | | 41 | 0�1 |
| 5,1-10,0 | — | — | — | — | | 50 | 0�1 |
| 1,0-5,9 | | | — | | — | 50 | 0�1 |
| 6,0-10,0 | | | — | | — | 41 | 0�1 |
| 1,0-10,0 | | | | | — | 19 | 0�5 |
| 1,0-13,0 | | | | | | 25 | 0�5 |
| 1,0-10,5 | | | — | | — | 24 | 0�5 (plus KB) |
Twist drill set HSS-Co
Design:
| - set of twist drills | DIN | M | ||
| HSS-Co | ||||
| - type Inox, 100420 in plastic box | 338 | Straight |
130° shank *Sizes 1.0-10.5 with tap hole dimensions 1 x each 3.3/4.2/6.8/10.2 mm
100596 PRECITOOL, Inox
| Xarea | 100596 | Quantity | increment each about |
| mm | of drills | mm | |
| 1,0-13,0 | | 25 | 0�5 |
| 1,0-10,5 | | 24 | 0�5 (plus KB) |
