| Solid Carbide End Mills | Centre cut shank | long | relieved | |||||||
| Design: | Use: | |||||||||
| 17 - unequal division | - universally applicable |
- long version - for roughing and finishing - shank with toric cut - with centre cut - cutting tips with 45° chamfer
- TiAlN coated Set: 4-piece
II ENNE
OLINOLINO
ECECEC ww rerte
rerr iseiswii we pr ive
175446 ECOLINE, Set, lang, mit Fase, TiAlN diedidd eii pternat
Al 33 (h10)
45°
4
175446 ECOLINE, long, with chamfer, TiAlN
| d | F | l | l | l | d | d | fz | ||
| 1 | 175446 | 1 | 2 | 4 | 3 | 2 | |||
| mm | mm | mm | mm | mm | mm | mm | mm/tooth | ||
| 3,00 | | 0�10 | 57 | 8 | 15 | 2�8 | 6 | 0�010 - 0�020 | |
| 4,00 | | 0�10 | 57 | 11 | 18 | 3�8 | 6 | 0�015 - 0�030 | |
| 5,00 | | 0�10 | 57 | 13 | 18 | 4�8 | 6 | 0�020 - 0�040 | |
| 6,00 | | 0�15 | 57 | 13 | 20 | 5�7 | 6 | 0�030 - 0�050 | |
| 8,00 | | 0�15 | 63 | 19 | 26 | 7�7 | 8 | 0�040 - 0�055 | |
| 10,00 | | 0�20 | 72 | 22 | 30 | 9�5 | 10 | 175446 ECOLINE, set, long, with chamfer, TiAlN 0�050 - 0�070 | |
| 12,00 | | 0�20 | 83 | 26 | 36 | 11�5 | 12 | 0�060 - 0�085 | |
| 14,00 | | 0�25 | 83 | 26 | 36 | 13�5 | 14 | 0�070 - 0�090 |
Type 175446 Contents
| 16,00 | | 0�35 | 92 | 32 | 42 | 15�5 | 16 | 0�080 - 0�120 | |||
| 20,00 | | 0�45 | 104 | 38 | 52 | 19�5 | 20 | 0�090 - 0�140 | SET | | 6 | 8 | 10 | 12 mm |
End mill VHM Universal, with toric cut
P M K Teeth
Cat. no. VHM Factory Blade form
| N/mm2 | HB N/mm2 | chamfer 4 standard | |
| 175487 | < 1200 | <300 < 850 | Centre cut coated |
| vc = m/min. | UNI | ||
| 175487 110-280 80-140 110-200 | |||
| 6535 HB Shank | |||
| Cutting data long shank relieved | |||
| Design: | Use: | ||
| - unequal division | - universally applicable | ||
| - long version | - for roughing and finishing | ||
| - shank with toric cut | - for large cutting depths | ||
| - cutting edges with a 45° chamfer | - extremely high cutting performance | ||
| - AlCrN coated | - very high running smoothness |
3 (h10)
45°
4
175487 PRECITOOL-GP, long, with chamfer, ALCRONA
| d | F | l | l | l | d | d | fz | ||
| 1 175487 | 1 | 2 | 4 | 3 | 2 | ||||
| mm | mm | mm | mm | mm | mm | mm | mm/tooth | ||
| 3,00 | | 0�13 | 57 | 8 | 18 | 2�8 | 6 | 0�007 - 0�028 | |
| 4,00 | | 0�18 | 57 | 11 | 21 | 3�8 | 6 | 0�010 - 0�035 | |
| 5,00 | | 0�20 | 57 | 13 | 21 | 4�8 | 6 | 0�015 - 0�035 | |
| 6,00 | | 0�20 | 57 | 13 | 21 | 5�5 | 6 | 0�025 - 0�040 | |
| 7,00 | | 0�20 | 63 | 19 | 27 | 6�5 | 8 | 0�030 - 0�045 | |
| 8,00 | 0�20 | 63 | 19 | 27 | 7�5 | 8 | 0�030 - 0�050 | Set II | |
| 9,00 | | 0�30 | 72 | 22 | 32 | 8�5 | 10 | 0�035 - 0�060 | |
| 10,00 | | 0�30 | 72 | 22 | 32 | 9�5 | 10 | 0�040 - 0�070 | |
| 11,00 | | 0�30 | 83 | 26 | 38 | 10�5 | 12 | 0�050 - 0�080 | 175487 PRECITOOL-GP, long, with chamfer, ALCRONA |
| 12,00 | | 0�30 | 83 | 26 | 38 | 11�5 | 12 | 0�060 - 0�090 | |
| 14,00 | | 0�30 | 83 | 26 | 42 | 13�5 | 14 | 0�070 - 0�110 | Contents 175487 Type |
| 18,00 | | 0�40 | 92 | 32 | 50 | 17�5 | 18 | 0�110 - 0�150 | Set 4-piece 6 | 8 | 10 | 12 mm SET |
| 20,00 | | 0�50 | 104 | 38 | 54 | 19�5 | 20 | 0�130 - 0�170 | Set 5-piece 6 | 8 | 10 | 12 | 16 mm SET II |
