End mill VHM Aluminium, with relived shank
| N | Plastics | Plastics | Teeth | ||||
| N/mm2 | N/mm2 | N/mm² | standard | 3 | 45° | ||
| Twist | 6535 HB |
| 175381 | Alu alloys, | PVC, PTFE, | Bakelite, | shank Centre cut coated CFK, GFK, fibre- |
| Copper alloys | ||||
| bronze, brass Alu <500 | thermoplastics | Melamine, | reinforced plastics | |
| 175383 | <500 | |||
| <500 | <100 | thermoset <150 | N <1500 | |
| Plastics |
vc = m/min. Shank Cutting data
| Solid Carbide End Mills | long | overlong | relieved | |
| 175381 |
| 17 | 450-600 | 225-350 | 300-400 | 450-550 | 360-460 | 225-380 | |
| 175383 |
| Design: | Use: | Note (175383): |
| - 45° even helix | - for aluminium and plastics | When used in Weldon chucks, please note |
| - long version (175381) | - for large cutting depths | the programming length! |
- extra long version (175383) - very high cutting performance - shank with toric cut - very high running smoothness - cutting points with protective chamfer - extended flute volume in
the front part of the cutting edge - ZrCN coated 3 3
(h10) (h10)
90° 90°
4 4 175381 175383
175381 PRECITOOL-GP, long, with protective chamfer, 175383 PRECITOOL-GP, extra long, with protective
sharp-edged, ZrCN chamfer, sharp-edged, ZrCN
| d1 mm | 175381 | Protective chamfer mm | l1 mm | l2 mm | l4 mm | d3 mm | d2 mm | fz mm/tooth | d1 mm | 175383 | Protective chamfer mm | l1 mm | l2 mm | l4 mm | d3 mm | d2 mm | fz mm/tooth |
| 3,00 | | 0�03 | 57 | 8 | 18 | 2�8 | 6 | 0�035 - 0�070 | 5,00 | | 0�05 | 63 | 22 | 29 | 4�8 | 6 | 0�045 - 0�090 |
| 4,00 | | 0�04 | 57 | 11 | 18 | 3�8 | 6 | 0�040 - 0�080 | 6,00 | | 0�06 | 63 | 22 | 29 | 5�5 | 6 | 0�060 - 0�120 |
| 5,00 | | 0�05 | 57 | 13 | 21 | 4�8 | 6 | 0�045 - 0�090 | 8,00 | | 0�08 | 80 | 28 | 36 | 7�5 | 8 | 0�080 - 0�160 |
| 6,00 | | 0�06 | 57 | 13 | 21 | 5�5 | 6 | 0�060 - 0�120 | 10,00 | | 0�10 | 80 | 33 | 43 | 9�5 | 10 | 0�090 - 0�180 |
| 8,00 | | 0�08 | 63 | 21 | 27 | 7�5 | 8 | 0�080 - 0�160 | 12,00 | | 0�10 | 100 | 33 | 54 | 11�5 | 12 | 0�100 - 0�200 |
| 10,00 | | 0�10 | 72 | 22 | 32 | 9�5 | 10 | 0�090 - 0�180 | 14,00 | | 0�10 | 100 | 48 | 54 | 13�5 | 14 | 0�110 - 0�200 |
| 12,00 | | 0�10 | 83 | 26 | 38 | 11�5 | 12 | 0�100 - 0�200 | 16,00 | | 0�10 | 125 | 53 | 69 | 15�5 | 16 | 0�120 - 0�210 |
| 14,00 | | 0�10 | 83 | 26 | 38 | 13�5 | 14 | 0�110 - 0�200 | 20,00 | | 0�10 | 150 | 68 | 84 | 19�5 | 20 | 0�140 - 0�220 |
| 16,00 | | 0�10 | 92 | 36 | 44 | 15�5 | 16 | 0�120 - 0�210 | |||||||||
| 18,00 | | 0�10 | 92 | 36 | 44 | 17�5 | 18 | 0�130 - 0�210 | |||||||||
| 20,00 | | 0�10 | 104 | 41 | 54 | 19�5 | 20 | 0�140 - 0�220 | |||||||||
| 25,00 | | 0�10 | 125 | 50 | 65 | 24�5 | 25 | 0�160 - 0�240 |
End mill VHM Universal
P K S N Factory Type Teeth
Cat. no. VHM Blade form
| N/mm2 | HB | N/mm2 | N/mm2 | standard | N | 30° chamfer 4 | ||||
| 175450 | Twist | |||||||||
| coated | ||||||||||
| < 1200 | <300 | Titanium <1200 Alu >600 Brass < 600 | ||||||||
| 175455 | UNI | |||||||||
| vc = m/min. | 6535 HB | |||||||||
| 175450 | 40-75 | 60-100 | 30-45 | 110-320 | 55-80 | Centre cut shank | long | overlong | ||
| 175455 | 65-130 | 95-165 | 45-70 | 180-550 | 90-130 |
45° (h9) 45° (h9)
175450 175455
175450 PRECITOOL, long/extra long, chamfered
175455 PRECITOOL, long/extra long, chamfered, ALCRONA
| d1× l2 mm | 175450 | 175455 | F mm | l1 mm | d2 mm | fz mm/tooth | d1× l2 mm | 175450 | 175455 | F mm | l1 mm | d2 mm | fz mm/tooth |
| 3,00×19 | | | 0�05 | 57 | 6 | 0�002 - 0�010 | 12,00×75 | | | 0�15 | 150 | 12 | 0�018 - 0�048 |
| 3,00×30 | | | 0�05 | 75 | 6 | 0�002 - 0�010 | 14,00×45 | | | 0�15 | 100 | 14 | 0�018 - 0�048 |
| 4,00×19 | | | 0�05 | 57 | 6 | 0�005 - 0�019 | 14,00×75 | | | 0�15 | 150 | 14 | 0�018 - 0�048 |
| 4,00×25 | | | 0�05 | 75 | 6 | 0�005 - 0�019 | 16,00×45 | | | 0�15 | 100 | 16 | 0�023 - 0�058 |
| 4,00×30 | | | 0�05 | 75 | 6 | 0�005 - 0�019 | 16,00×75 | | | 0�15 | 150 | 16 | 0�023 - 0�058 |
| 5,00×30 | | | 0�05 | 75 | 6 | 0�006 - 0�020 | 16,00×90 | | | 0�15 | 150 | 16 | 0�023 - 0�058 |
| 5,00×40 | | | 0�05 | 100 | 6 | 0�006 - 0�020 | 18,00×45 | | | 0�15 | 100 | 18 | 0�023 - 0�058 |
| 6,00×30 | | | 0�05 | 75 | 6 | 0�008 - 0�025 | 18,00×75 | | | 0�15 | 150 | 18 | 0�023 - 0�058 |
| 6,00×40 | | | 0�05 | 100 | 6 | 0�008 - 0�025 | 20,00×45 | | | 0�15 | 100 | 20 | 0�028 - 0�073 |
| 8,00×30 | | | 0�10 | 75 | 8 | 0�012 - 0�032 | 20,00×75 | | | 0�15 | 150 | 20 | 0�028 - 0�073 |
| 8,00×40 | | | 0�10 | 100 | 8 | 0�012 - 0�032 | 20,00×90 | | | 0�15 | 150 | 20 | 0�028 - 0�073 |
| 10,00×30 | | | 0�10 | 75 | 10 | 0�015 - 0�039 | 25,00×45 | | | 0�20 | 100 | 25 | 0�028 - 0�073 |
| 10,00×40 | | | 0�10 | 100 | 10 | 0�015 - 0�039 | 25,00×75 | | | 0�20 | 150 | 25 | 0�028 - 0�073 |
| 10,00×60 | | | 0�10 | 125 | 10 | 0�015 - 0�039 | 25,00×90 | | | 0�20 | 150 | 25 | 0�028 - 0�073 |
| 12,00×45 | | | 0�15 | 100 | 12 | 0�018 - 0�048 | — | — | — | — | — | — | — |
