Solid Carbide End Mills End mill VHM Universal Cat. no. PN/mm2 MN/mm2 KHB VHM Factory Teethstandard3 6535 HA 175309 < 1200 < 850 < 650 coated Centre cut shank vc = m/min. 175309 110-280 80-110 110-200 UNI P9 extra short Cutting data Design: - unequal division- extra short version- cutting points with protective chamfer 17 - extended flute volume in the front part of the cutting edge - for fit P9 - AlCrN coated Use: - universally applicable - for roughing and finishing - for large cutting depths - extremely high cutting performance - very high running smoothness (e8) 90° 175309 PRECITOOL-GP, extra short, P9, with protective chamfer, sharp-edged, ALCRONA d1mm 175309 Protective chamfer l1 l2 d2mmmmmmmm fzmm/tooth d1mm 175309 Protective chamfer l1 l2 d2mmmmmmmm fzmm/tooth 1,00  0.02 40 2 3 0.006 - 0.015 7,75  0.08 45 11 8 0.030 - 0.045 1,50  0.02 40 3 3 0.006 - 0.015 8,00  0.08 45 11 8 0.030 - 0.050 2,00  0.02 40 3 6 0.007 - 0.020 8,70  0.09 50 13 10 0.030 - 0.050 2,50  0.02 40 3 6 0.007 - 0.020 9,00  0.09 50 13 10 0.035 - 0.060 2,80  0.03 40 5 6 0.007 - 0.020 9,70  0.10 50 13 10 0.035 - 0.060 3,00  0.03 40 5 6 0.007 - 0.028 10,00  0.10 50 13 10 0.040 - 0.070 3,80  0.04 40 7 6 0.007 - 0.028 11,70  0.12 55 15 12 0.050 - 0.080 4,00  0.04 40 7 6 0.010 - 0.035 12,00  0.12 55 15 12 0.060 - 0.090 4,80  0.05 40 8 6 0.010 - 0.035 13,70  0.14 58 15 14 0.060 - 0.090 5,00  0.05 40 8 6 0.015 - 0.035 14,00  0.14 58 15 14 0.070 - 0.110 5,75  0.06 40 8 6 0.015 - 0.035 15,70  0.15 62 18 16 0.070 - 0.110 6,00  0.06 40 8 6 0.025 - 0.040 16,00  0.15 62 18 16 0.090 - 0.130 6,75  0.07 45 11 8 0.025 - 0.040 18,00  0.15 70 18 18 0.110 - 0.150 7,00  0.07 45 11 8 0.030 - 0.045 20,00  0.15 75 22 20 0.130 - 0.170 End mill VHM Universal Cat. no. PN/mm2 MN/mm2 KHB VHM Factory Teeth Blade formstandard3chamfer 175315 < 1200 < 850 < 650 coated Centre cut vc = m/min. 175315 110-280 80-110 110-200 6535 HB UNI shank short Cutting data Design: - unequal division - short version - cutting edges with a 45° chamfer - extended flute volume in the front part of the cutting edge - AlCrN coated Use: - universally applicable - for roughing and finishing - for large cutting depths - extremely high cutting performance - very high running smoothness (h10) 45° 175315 PRECITOOL-GP, short, with chamfer, ALCRONA d1mm 175315 F l1 l2 d2mmmmmmmm fzmm/tooth d1mm 175315 F l1 l2 d2mmmmmmmm fzmm/tooth 2,00  0.10 54 4 6 0.007 - 0.020 8,00  0.20 58 12 8 0.030 - 0.050 2,50  0.10 54 4 6 0.007 - 0.020 9,00  0.30 66 14 10 0.035 - 0.060 3,00  0.13 54 6 6 0.007 - 0.028 10,00  0.30 66 14 10 0.040 - 0.070 3,50  0.13 54 6 6 0.007 - 0.028 12,00  0.30 73 16 12 0.060 - 0.090 4,00  0.18 54 8 6 0.010 - 0.035 14,00  0.30 75 18 14 0.070 - 0.110 5,00  0.20 54 9 6 0.015 - 0.035 16,00  0.40 82 22 16 0.090 - 0.130 6,00  0.20 54 10 6 0.025 - 0.040 20,00  0.50 92 26 20 0.130 - 0.170 7,00  0.20 58 12 8 0.030 - 0.045 — — — — — — — www.precitool.de 17/247
