Tap Drills Machine tap Steel Cat. no. PN/mm2 NN/mm2 PlasticsN/mm2 MF HSS-E Chamfer form B Metric fineDIN60° DINMetricV3374L13 6H 133205 < 900 Copper < 900 Alu <500 Thermoplastics fine thread 3,5-5 threads vc = m/min. 133205 6-10 8-12 18-26 18-26 P Through hole Design: Use: - for through-hole threads For easy to machine materials.- chamfer form B, 3.5-5 thread- made of high-speed steel with 13 vanadium content 133205 PRECITOOL, HSSE-V3, blank d1 × P 133205 l l1 2mmmm d 2mm amm l 3 Core mmmm d1 × P 133205 l 1mm l 2mm d 2mm amm l3 Core mmmm M3×0,35  56 8  2.2 — —  2.65 M20×1,50  125 25 16.0 12.0 15 18.50 M4×0,50  63 10  2.8  2.1 5  3.50 M20×2,00  140 34 16.0 12.0 15 18.00 M5×0,50  70 12  3.5  2.7 6  4.50 M22×1,00  125 25 18.0 14.5 17 21.00 M6×0,50  80 14  4.5  3.4 6  5.50 M22×1,50  125 25 18.0 14.5 17 20.50 M6×0,75  80 14  4.5  3.4 6  5.25 M22×2,00  140 34 18.0 14.5 17 20.00 M7×0,75  80 14  5.5  4.3 7  6.25 M24×1,00  140 28 18.0 14.5 17 23.00 M8×0,50  80 18  6.0  4.9 8  7.50 M24×1,50  140 28 18.0 14.5 17 22.50 M8×0,75  80 18  6.0  4.9 8  7.25 M24×2,00  140 28 18.0 14.5 17 22.00 M8×1,00  90 22  6.0  4.9 8  7.00 M25×1,50  140 28 18.0 14.5 17 23.50 M9×1,00  90 22  7.0  5.5 8  8.00 M26×1,50  140 28 18.0 14.5 17 24.50 M10×0,75  90 20  7.0  5.5 8  9.25 M27×1,50  140 28 20.0 16.0 19 25.50 M10×1,00  90 20  7.0  5.5 8  9.00 M27×2,00  140 28 20.0 16.0 19 25.00 M10×1,25  100 24  7.0  5.5 8  8.75 M28×1,50  140 28 20.0 16.0 19 26.50 M11×1,00  90 20  8.0  6.2 9 10.00 M30×1,00  150 28 22.0 18.0 21 29.00 M12×1,00  100 22  9.0  7.0 10 11.00 M30×1,50  150 28 22.0 18.0 21 28.50 M12×1,25  100 22  9.0  7.0 10 10.75 M30×2,00  150 28 22.0 18.0 21 28.00 M12×1,50  100 22  9.0  7.0 10 10.50 M32×1,50  150 28 22.0 18.0 21 30.50 M14×1,00  100 22 11.0  9.0 12 13.00 M33×1,50  160 30 25.0 20.0 23 31.50 M14×1,25  100 22 11.0  9.0 12 12.75 M34×1,50  170 30 28.0 22.0 25 32.50 M14×1,50  100 22 11.0  9.0 12 12.50 M35×1,50  170 30 28.0 22.0 25 33.50 M15×1,00  100 22 12.0  9.0 12 14.00 M36×1,50  170 30 28.0 22.0 25 34.50 M15×1,50  100 22 12.0  9.0 12 13.50 M38×1,50  170 30 28.0 22.0 25 36.50 M16×1,00  100 22 12.0  9.0 12 15.00 M40×1,50  170 30 32.0 24.0 27 38.50 M16×1,50  100 22 12.0  9.0 12 14.50 M42×1,50  170 30 32.0 24.0 27 40.50 M18×1,00  110 25 14.0 11.0 14 17.00 M45×1,50  180 32 36.0 29.0 32 43.50 M18×1,50  110 25 14.0 11.0 14 16.50 M48×1,50  190 32 36.0 29.0 32 46.50 M18×2,00  125 34 14.0 11.0 14 16.00 M50×1,50  190 32 36.0 29.0 32 48.50 M20×1,00  125 25 16.0 12.0 15 19.00 — — — — — — — — Machine tap Steel Cat. no. PN/mm2 NN/mm2 MF Metric HSS-Co DIN374 Chamfer form C DINL13 133211 < 850 Alu < 600 Zinc fine thread coated 35°Twist 2,5 threads vc = m/min. 133211 6-10 12-20 8-10 6H 1.5 × D P Blind hole The toSfoTprEEgLesnmeearcalhllieninrg 133211 ECOLINE, HSS-Co, RSP35, steam tempered d1 × P 133211 l1 l2mmmm d2mm amm Core mm d1 × P 133211 l1 l2mmmm d2mm amm Core mm M4×0,50  63 7  2.8 2.1  3.50 M16×1,00  100 16 12.0 9.0 15.00 M5×0,50  70 8  3.5 2.7  4.50 M16×1,50  100 16 12.0 9.0 14.50 M6×0,75  80 10  4.5 3.4  5.20 M18×1,00  110 20 14.0 11.0 17.00 M8×0,75  80 10  6.0 4.9  7.20 M18×1,50  110 20 14.0 11.0 16.50 M8×1,00  90 13  6.0 4.9  7.00 M20×1,00  125 20 16.0 12.0 19.00 M10×1,00  90 12  7.0 5.5  9.00 M20×1,50  125 20 16.0 12.0 18.50 M10×1,25  100 15  7.0 5.5  8.80 M22×1,50  125 20 18.0 14.5 20.50 M12×1,00  100 14  9.0 7.0 11.00 M24×1,50  140 22 18.0 14.5 22.50 M12×1,25  100 14  9.0 7.0 10.80 M24×2,00  140 22 18.0 14.5 22.00 M12×1,50  100 14  9.0 7.0 10.50 M26×1,50  140 22 18.0 14.5 24.50 M14×1,00  100 16 11.0 9.0 13.00 M30×1,50  150 26 22.0 18.0 28.50 M14×1,25  100 16 11.0 9.0 12.80 M30×2,00  150 26 22.0 18.0 28.00 M14×1,50  100 16 11.0 9.0 12.50 — — — — — — — www.precitool.de 13/181
