| P | M | K | S | N | Plastics | M | HSS-E | DIN | DIN | Metric Chamfer form C | ||
| N/mm2 | N/mm2 | HB | N/mm2 | N/mm2 | N/mm2 | V3 | 371 | 376 | ||||
| Metric | ||||||||||||
| 132250 | < 1100 | < 800 | < 250 Titanium < 900 Nickel < 900 Thermoset GRP / CRP / ARP | thread | from M12 | 40°Twist | L | |||||
| 2-3 threads | ||||||||||||
| vc = m/min. | DIN | UNI | ||||||||||
| 132250 | 6-8 | 5-6 | 8-10 | 2-4 | 2-4 | 8-10 | 8-10 | 6H | 2.5 × D |
13 Blind hole 13 Design: - for blind hole thread
- form C, 40 grade RSP - high-speed steel with vanadium content - vaporized
Use: For universal use.
132250 PRECITOOL, HSSE-V3, RSP40, vaporised
| d | P | l | l | l | d | a | l | Core x | |
| 1 | 132250 | 1 | 2 | 4 | 2 | 3 | |||
| mm | mm | mm | mm | mm | mm | mm | mm | mm | |
| M3 | | 0�50 | 56 | 5 | 18 | 3�5 | 2�7 | 6 | 2�50 |
| M4 | | 0�70 | 63 | 7 | 21 | 4�5 | 3�4 | 6 | 3�30 |
| M5 | | 0�80 | 70 | 8 | 25 | 6�0 | 4�9 | 8 | 4�20 |
| M6 | | 1�00 | 80 | 10 | 30 | 6�0 | 4�9 | 8 | 5�00 |
| M8 | | 1�25 | 90 | 13 | 35 | 8�0 | 6�2 | 9 | 6�80 |
| M10 | | 1�50 | 100 | 15 | 39 | 10�0 | 8�0 | 11 | 8�50 |
| M12 | | 1�75 | 110 | 18 | — | 9�0 | 7�0 | 10 | 10�20 |
| M16 | | 2�00 | 110 | 20 | — | 12�0 | 9�0 | 12 | 14�00 |
| M20 | | 2�50 | 140 | 25 | — | 16�0 | 12�0 | 15 | 17�50 |
| M24 | | 3�00 | 160 | 30 | — | 18�0 | 14�5 | 17 | 21�00 |
Machine tap Universal
| P | M | K | S | N | Plastics | M | HSS- | DIN | DIN | Metric Chamfer form B | |
| Cat. no. | 60° | ||||||||||
| N/mm2 | N/mm2 | HB | N/mm2 | N/mm2 | N/mm2 | Co PM | 371 | 376 | |||
| Metric | |||||||||||
| from M12 | L | ||||||||||
| thread | coated | 3,5-5 threads | |||||||||
| 132210 | < 1200 | < 900 | <300 | <1000 Brass, bronze, alu < 600 Thermoplastics, | |||||||
| CFRP, GFRP | |||||||||||
| DIN | UNI | ||||||||||
| vc = m/min. | 6HX | ||||||||||
| 13 | |||||||||||
| 132210 | 10-17 | 8-10 | 15-22 | 2-3 | 32-60 | 15-26 |
Through hole Design/use: - for through-hole threads - chamfer form B, 3.5-5 thread
Machine tap made of powder-metallurgically HSS (PS55) with excellent cutting characteristics, toughness and process reliability. The manufacturing tolerance of 6HX ensures longer life and better trueness to gauge size with clamping materials. Due to universal use in almost all materials great potential for savings. The helix angle of 50 ° and the optimized flute geometry guarantee excellent chip evacuation to 3 × d thread depth. Hardlube coating (multilayer) reduces wear and surface friction.
Dimensions: ≤ M6 = solid point > M8 = internal centring
132210 HighQ, HSS-Co PM, Hardlube
| d | P | l | l | l | d | a | l | Core x | |
| 1 | 132210 | 1 | 2 | 4 | 2 | 3 | |||
| mm | mm | mm | mm | mm | mm | mm | mm | mm | |
| M2 | | 0�40 | 45 | 8 | — | 2�8 | 2�1 | 5 | 1�60 |
| M2,5 | | 0�45 | 50 | 9 | — | 2�8 | 2�1 | 5 | 2�05 |
| M3 | | 0�50 | 56 | 11 | 18 | 3�5 | 2�7 | 6 | ersal 2�50 |
| M4 | | 0�70 | 63 | 13 | 21 | 4�5 | 3�4 | 6 | Univ 3�30 |
| M5 | | 0�80 | 70 | 16 | 25 | 6�0 | 4�9 | 8 | 4�20 |
| M6 | | 1�00 | 80 | 19 | 30 | 6�0 | 4�9 | 8 | 5�00 |
| M8 | | 1�25 | 90 | 22 | 35 | 8�0 | 6�2 | 9 | 6�80 |
| M10 | | 1�50 | 100 | 24 | 39 | 10�0 | 8�0 | 11 | 8�50 |
| M12 | | 1�75 | 110 | 28 | — | 9�0 | 7�0 | 10 | 10�20 |
| M14 | | 2�00 | 110 | 30 | — | 11�0 | 9�0 | 12 | 12�00 |
| M16 | | 2�00 | 100 | 32 | — | 12�0 | 9�0 | 12 | 14�00 |
| M20 | | 2�50 | 140 | 34 | — | 16�0 | 12�0 | 15 | 17�50 |
| M24 | | 3�00 | 160 | 38 | — | 18�0 | 14�5 | 17 | 21�00 |
| M27 | | 3�00 | 160 | 38 | — | 20�0 | 16�0 | 19 | 24�00 |
| M30 | | 3�50 | 180 | 45 | — | 22�0 | 18�0 | 21 | 26�50 |
