Air gun Design: - air volume doseable by means of operating lever - can be used for delicate blow-out operations - nozzle thread M12 × 1.25 925832 Aluminium, forged Type 925832 Nozzle boremm Connection 0010  1.5 G 1/4" internal thread 0012  1.5 with coupling plug NW 7.2 0014  1.5 with 6 mm hose connection 0016  1.5 with 9 mm hose connection 0030  — G 1/4" internal thread without nozzle Accessories for blowguns Design: Design: Type 0032 For nozzle mounting in aluminium blowguns - spare nozzle for air gun 925832 0010-0016 - nozzle bore 1.5 mm Type 0034 - safety nozzle with centre bore and lateral annular gap or side hole - shield formation against rebounding chips - air venting through the annular gap or side hole when closing the nozzle bore Type 0035- noise protection nozzle with sintered metal insert 925832 Adapter for nozzle mounting - low noise level of about 63 - 73 dB (A)- good blowing effect with up to 380 l/min Type 925832 Threadexternal Threadinside Type 0037 0079  M12 × 1.25 G 1/4" - noise protection nozzle - nozzle insert made of hard PVC - temperature range up to max. 90 °C Design: - air consumption 150 l/min. at 4 bar - pressure range up to max. 6 bar - powerful point-impinging air jet, low noise level - temperature range from POM max. +50 °C, aluminium max. +200 °C - up to 12 dB(A) quieter than conventional single-hole nozzle - multi-channel fan nozzles are particularly quiet and economical - especially suitable for wide-scale blowing off of water or dust as well as blowing out and further transport of stampings, plastic and elastomer moul- ded parts 0032 0034 0035 0037 0071 + 0073 0074 925832 Nozzle 925832 Multi-channel fan nozzle Type0032 925832 ThreadexternalM12 × 1.25 Type 925832 ThreadexternalNozzle widthmmAir consumptionat 4 barin l/minDesign 0034  M12 × 1.25 0071  R 1/4" 47 550 Eco-Line, ABS, blue 0035  M12 × 1.25 0073  G 1/4" 51 416 POM, blue 0037  M12 × 1.25 0074  G 1/4" 51 416 Aluminium Design: - for mounting behind the nozzle - rebounding chips are held back - please order matching nozzle separately (925832 0034) 0036-0040 0042-0048 92 925832 Extension pipe, straight/curved Type 925832 Pipe lengthmm Threadexternal Design 0036  100 M12 × 1.25 curved 0038  150 M12 × 1.25 curved 925832 Protective shield 0040  250 M12 × 1.25 curved 0042  100 M12 × 1.25 straight Type 925832 Thread 0044  150 M12 × 1.25 straightexternal0046250M12 × 1.25straight 0050  M12 × 1.25 0048  400 M12 × 1.25 straight www.precitool.de 92/1265 Coolants / Lubricants / Compressed Air
