Bench shears Design: - robust construction made of tempered steel - removable lever for easy carrying - the blades are hardened and ground - this guarantees a maximum tool life Use: For sheet material, flat rolled and round-bar steel 593010 Bench shears 593015 Spare upper blade 593018 Spare lower shear blade Type 593010 593015 593018 Cutting capacity:Steel sheetmmFlat steelmm Round steelmm Blade lengthmm Weight (net)kg 2/BR4    4 50 × 4 11 120 8 2/BR5    5 50 × 5 11 150 10 2/BR6    6 70 × 6 13 180 18 Manual toggle lever press Design: - transmission via toggle mechanism - this kind of construction deigns amazing high pressures despite its rather compact dimensions - important to note: at toggle lever transmission, the maximum pressure output is not reached until the toggle lever is straight, i.e. shortly before end of stroke - precise in operation - working height can be adjusted by simply loosening the clamping screws on the stand - hand lever user-friendly arranged - return via spring - spindle hardened and ground - long spindle guide for optimum pressure performance - T-slot centrically milled according to DIN 650 Type HK800: Additionally with working height fine-tuning for millimetre-exact adjustment of the HK800 press head to the desired working height. The fine-tuning is achieved in both directions via a threaded spindle 593250 with toggle Type 593250 Compressiveforceapprox. kNStrokemmWorking height adjustablefrom - tommSpindle x /table areammSpindle holemmReach/bench areammT-slot widthDIN 650mmHeight of columnmmBase areammWeightapprox.kg HK500  5 40 60 - 150  20 10 H7 73/115 ×   70 10 290 115 × 175 10 HK800  8 40 50 - 200  24 10 H7 90/120 × 160 12 410 160 × 230 22 Manual toggle lever press 59 Design: - power transmission by means of a gear rack - contrary to presses with toggle these kind of constructions offer full pressure capacity over the entire stroke length - they are used wherever non-varying pressure is required HZ150 593300 with gear rack Type 593300 Compressiveforceapprox. kNStrokemmWorking height adjustablefrom - tommSpindle x /table areammSpindle holemmReach/bench areammT-slot widthDIN 650mmHeight of columnmmBase areammWeightapprox.kg HZ150  1.5 40 75 - 170  20 10 H7 70/115 ×   70 10 290 115 × 175 9.5 HZ250  2.5 45 80 - 220  20 10 H7 90/120 × 160 12 390 160 × 230 22.0 www.precitool.de 59/1157 Pullers / Sheet Metal Treatment
