Parallel vice Design: - entirely made of steel, forged - large, all-round machined surfaces - opening to the front, with forged-on hardened tube clamping jaws beneath - protected and machined precision spindle bearing the standard jaws - fast opening and closing by a two-sided trapezoidal thread spindle - great stability due to sturdy, centrically positioned spindle - large deep clamping possibility due to compact dimensions - high and optimally distributed clamping force - surface-hardened and milled jaw surfaces, with reinforced anvil attachment for - centric (without special tool) adjustable, very well protected against damaging straightening work and contamination by prism guide 588620 588680 588650 588600 588600 HEUER, with fixed jaws 588620 HEUER, with exchangeable jaws 588650 Turntable 588680 Spare jaws (only for 588620) Jaw widthmm 588600 588620 Clampingrangemmfor tube x (tubularchuck jaw)mmWeightkg Jaw widthmm 588650 588680 100  — 125 16 -   30  4.5 100  — 120   150 16 -   55  9.0 120   140   200 27 -   70  16.0 140   160 + + 225 27 - 100  27.0 160/180  — 180 + — 225 27 - 100  29.0 160 —  Collapsible lift for bench vices Design and use: - even better clamping force through special surface treatment of the column plus a novel clamping bracket - adjustment to the body height of the operator is vital for ergonomic working - effortless and easy adjustment of vices by 200 mm, rotatable by 360° - a gas pressure spring, attuned to the respective vice weight, makes the vice practically weightless; hence it can be brought into the desired working position almost without the need for force after releasing the clamping lever - suitable for HEUER vice Delivery: Without vice 588700 HEUER-LIFT for jaw widthmm 588700 100  120  140  160  180  58 Fold & stow adjustable height stand Design: - solid steel construction, easy handling - in working position the vice is stable and vibration-free connected to the bench, however it may be folded away in brief below the bench - two telescopic shock absorbers keep the vice in equilibrium in any position and thus reduce the risk of injury - suitable for HEUER vices and many other brands Vice and holder can 588800 Folding device HEUER-Klapp 588800 588820 be folded underthe workbench in 588820 Folding lift HEUER-Klapp a few steps for jaw widthmm 588800 588820 Weight HEUER Klapp (foldaway)kg Weight HEUER foldaway liftkg 120   5.6 14 140   5.6 14 www.precitool.de 58/1141 Shears / Clamping Tools
